DF2B7AFU

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

联系我们

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Internal Connection	Single
Number of Circuits	1
Number of Protected Lines	1
Configuration	Bidirectional
Application	USB1.1 / Audio / SIM-Card / Power supply
RoHS Compatible Product(s) (#)	Available

封装

package name (TOSHIBA)	SOD-323 (USC)
Package Image
package code	SOD-323
Pins	2
Mounting	Surface Mount
Width×Length×Height (mm)	2.5×1.25×0.9
Package Dimensions	查看
Land pattern dimensions	查看
Ultra Librarian^® CAD model (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note1)(Note3)
SamacSys CAD model (Symbol, Footprint and 3D model)	Download from SamacSys (Note2)(Note3)

Please refer to the link destination to check the detailed size.

(Note1)	Ultra Librarian^® is a Registered trademark and CAD model library of EMA (EMA Design Automation, Inc.). CAD models (Symbol/Footprint /3D model) are provided by UltraLibrarian^®. The footprints are generated based on the specifications of Ultra Librarian^®.
(Note2)	SamacSys is a wholly owned subsidiary of Supplyframe, Inc. CAD models (Symbol/Footprint /3D model) are provided by Supplyframe, Inc. The footprints are generated based on the specifications of SamacSys.
(Note3)	Please note that the footprint dimensions may differ from the reference Land Pattern dimensions provided on our website.

绝对最大额定值

项目	符号	值	单位
Electrostatic discharge voltage(IEC61000-4-2)	V_ESD	+/-30	kV
Peak pulse current (IEC61000-4-5)	I_PP	4	A

电气特性

项目	符号	条件	值	单位
Working peak reverse voltage (Max)	V_RWM	-	+/-5.5	V
Total Capacitance (Max)	C_T	V_R=0V f=1MHz	10	pF
Total Capacitance (Typ.)	C_T	V_R=0V f=1MHz	8.5	pF
Dynamic resistance (Typ.)	R_dyn	I_PP=8A to 16A	0.2	Ω
Reverse Breakdown Voltage (Min)	V_BR	I_BR=1mA	5.8	V
Reverse Current (Max)	I_R	V_RWM=5.5V	0.1	μA
Clamp voltage (Based on IEC61000-4-5) (Typ.)	V_C	I_PP=1A	8	V

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	Note
DF2B7AFU	3000		Yes	General Use

应用

电动剃须刀

低功耗和小型化对于电动剃须刀的设计非常重要的。东芝提供了适用于电源装置、浪涌电压保护装置、电机驱动装置等的各种半导体产品的信息以及电路配置示例。

详细信息

电子血压计

低功耗和小型化对于电子血压计的设计非常重要的。东芝提供了适用于电源装置、浪涌电压保护装置、电机驱动装置、传感器信号输入装置等的各种半导体产品的信息以及电路配置示例。

详细信息

人体成分分析仪

低功耗和小型化对于人体成分分析仪的设计非常重要。东芝公司提供了适用于电源装置、传感器信号输入装置、显示装置等的各种半导体产品的信息以及电路配置示例。

详细信息

血糖仪

低功耗和小型化对于血糖仪的设计非常重要。东芝提供了适用于电源单元、浪涌电压保护单元、传感器信号输入单元等的各种半导体产品的信息，以及电路配置示例。

详细信息

可编程逻辑控制器

在设计可编程逻辑控制器（PLC）时，高功能性、低功耗和小型化等非常重要。东芝提供适用于电源单元、输入和输出模块单元、控制信号传输单元等的各种半导体产品的信息以及电路配置示例。

详细信息
