Brushed DC Motor Driver ICs

Toshiba offers brushed motor drivers fabricated using a CDMOS or BiCDMOS process that exhibits low output Ron and thus helps reduce power consumption. Toshiba's product portfolio contains a wide range of brushed motor drivers with extensive supply voltage, output current and channel count options. Toshiba's product offerings include motor drivers that consist of multiple H-bridges that can be combined in a flexible manner according to the types of motors driven (stepping motors and brushed DC motors) and the required current capabilities.

Lineup

TC78H653FTG

TC78H653FTG

The dual-H-bridge TC78H653FTG delivers the low voltage (1.8V) and high current (4.0A) essential for motor-based equipment powered by relatively low voltage batteries in the range of 1.8V to 7.0V.  Suitable for applications using 3.7V lithium-ion batteries or products such as electronic locks, smart meters, and toys using two 1.5V dry batteries, as well as devices based on a 5V USB power supply.

TC78H651AFNG

TC78H651AFNG

The TC78H651AFNG is a dual H-bridge motor drive IC that delivers performance at a low voltage (down to 1.8V) and high current (up to 2A) that is essential for equipment powered by dry-cell batteries.  The new device is suitable for motor applications such as cameras and compact printers using 3.7V lithium-ion batteries, toys and home appliances, smart meters, and electronic locks using two 1.5V dry batteries, and devices using 5V USB power supplies.

Single-Channel Motor Drivers

Product Lines :Single-Channel Motor Drivers

Dual-Channel Motor Drivers

Product Lines :Dual-Channel Motor Drivers

Video

Recommended products

Parametric Search

Brushed Motor Drivers Product Lineup

Cross Reference Search

About information presented in this cross reference

The information presented in this cross reference is based on TOSHIBA's selection criteria and should be treated as a suggestion only. Please carefully review the latest versions of all relevant information on the TOSHIBA products, including without limitation data sheets and validate all operating parameters of the TOSHIBA products to ensure that the suggested TOSHIBA products are truly compatible with your design and application.
Please note that this cross reference is based on TOSHIBA's estimate of compatibility with other manufacturers' products, based on other manufacturers' published data, at the time the data was collected.
TOSHIBA is not responsible for any incorrect or incomplete information. Information is subject to change at any time without notice.

Simulation

Downloading PSpice® models

Contacts

Technical inquiry

Contact us

Contact us

Frequently Asked Questions

FAQs

Queries about purchasing, sampling and IC reliability

Stock Check & Purchase

keyword:

* PSpice is a registered trademark of Cadence Design Systems, Inc.

TB67H450FNG/TB67H451FNG

A compact, highly energy efficient, single-channel H-bridge driver family, consisting of two devices: TB67H450 and H451, is offering a maximum rating of 50V/3.5A and low standby current of just 1uA. Housed in a compact, HSOP8 surface mount package and featuring a popular pinout, both MCDs are ideal for new DC brushed motor designs or as a plug-in replacement to improve and upgrade existing applications in addition to offering more product sourcing options.
