Such as low power consumption and miniaturization are important in designing uninterruptible power supply (UPS). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, inverter/converter units, control units, signal transmission units, etc., along with circuit configuration examples.
Click the area you want to check the details in the overall block diagram. Show links to our proposed sub-block diagram.
Example of ESD protection circuit for USB signal line
Example of ESD protection circuit for RS-232C signal line
Example of ESD protection circuit for a display signal line
Example of control signal transmission circuit between MCU and converter
Example of communication signal transmission circuit between MCUs
Example of voltage and current detection signal transmission circuit between power line and MCU
Example of DC-DC converter and control circuit
Example of power supply circuit to analog front end
Example of power supply circuit to main MCU
Example of power supply circuit to communication MCU
Click the area you want to check the details in the overall block diagram. Show links to our proposed sub-block diagram.
Example of AC-DC converter (with PFC circuit) and control circuit
Example of power supply circuit to main MCU
Click the area you want to check the details in the overall block diagram. Show links to our proposed sub-block diagram.
Example of DC-AC inverter and control circuit
Example of power supply circuit to main MCU
Example of ESD protection circuit for USB signal line
Part Number | |||
---|---|---|---|
Toshiba Package Name | SOD-962 (SL2) | SOD-962 (SL2) | SOD-962 (SL2) |
VESD (Max) [kV] | +/-30 | +/-20 | +/-20 |
IR (Max) [µA] | 0.1 | 0.1 | 0.1 |
Rdyn (Typ.) [Ω] | 0.2 | 0.5 | 0.5 |
CT (Typ.) [pF] @ VR = 0 [V], f = 1 [MHz] | 8.5 | 0.2 | 0.2 |
Example of ESD protection circuit for RS-232C signal line
Part Number | |||
---|---|---|---|
Toshiba Package Name | SOD-962 (SL2) | SOD-962 (SL2) | SOD-962 (SL2) |
VESD (Max) [kV] | +/-30 | +/-20 | +/-20 |
IR (Max) [µA] | 0.1 | 0.1 | 0.1 |
Rdyn (Typ.) [Ω] | 0.2 | 0.5 | 0.5 |
CT (Typ.) [pF] @ VR = 0 [V], f = 1 [MHz] | 8.5 | 0.2 | 0.2 |
Example of ESD protection circuit for a display signal line
Part Number | |||
---|---|---|---|
Toshiba Package Name | SOD-962 (SL2) | SOD-962 (SL2) | SOD-962 (SL2) |
VESD (Max) [kV] | +/-30 | +/-20 | +/-20 |
IR (Max) [µA] | 0.1 | 0.1 | 0.1 |
Rdyn (Typ.) [Ω] | 0.2 | 0.5 | 0.5 |
CT (Typ.) [pF] @ VR = 0 [V], f = 1 [MHz] | 8.5 | 0.2 | 0.2 |
Example of control signal transmission circuit between MCU and converter
Part Number | ||||||
---|---|---|---|---|---|---|
Toshiba Package Name | SO16L | SO16L | SO16L | SO16L | SO6L | SO6L |
BVS (Min) [Vrms] @ t = 60 [s] | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 |
VCC / VDD (Min) [V] | 15 | 15 | 15 | 15.0 | 15 | 15 |
VCC / VDD (Max) [V] | 30 | 30 | 30 | 23.5 | 30 | 30 |
ICC / IDD (Max) [mA] | 3.8 | 5 | 5 | 10.2 | 3 | 3 |
Output Interface | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) |
Example of communication signal transmission circuit between MCUs
Part Number | ||||||
---|---|---|---|---|---|---|
Toshiba Package Name | SO6L | SO6L | SO6L | SO8L(LF4) | SO8L(LF4) | SO8L(LF4) |
BVS (Min) [Vrms] @ t = 60 [s] | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 |
VCC / VDD (Min) [V] | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 |
VCC / VDD (Max) [V] | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
ICC / IDD (Max) [mA] | 0.3 | 1 | 0.4 | 0.6 | 2 | 0.8 |
Output Interface | totem-pole(BUF) | totem-pole(INV) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(INV) | totem-pole(BUF) |
Example of voltage and current detection signal transmission circuit between power line and MCU
Example of DC-DC converter and control circuit
Part Number | ||||
---|---|---|---|---|
Toshiba Package Name | TO-247 | TO-247 | TO-247-4L(X) | TO-247-4L(X) |
VDSS (Max) [V] | 650 | 1200 | 650 | 1200 |
ID (Max) [A] | 100 | 100 | 100 | 100 |
RDS(ON) (Max) [Ω] @ |VGS| = 18.0 [V] | 0.021 | 0.02 | 0.022 | 0.021 |
Polarity | N-ch | N-ch | N-ch | N-ch |
Part Number | |||||
---|---|---|---|---|---|
Toshiba Package Name | TSON Advance | SOP Advance(N) | SOP Advance | SOP Advance / SOP Advance(N) | TO-220SIS |
VDSS (Max) [V] | 80 | 80 | 80 | 150 | 80 |
ID (Max) [A] | 34 | 86 | 120 | 64 | 100 |
RDS(ON) (Max) [Ω] @ |VGS| = 10.0 [V] | 0.019 | 0.004 | 0.00243 | 0.009 | 0.00244 |
Polarity | N-ch | N-ch | N-ch | N-ch | N-ch |
Part Number | ||||||
---|---|---|---|---|---|---|
Toshiba Package Name | SO16L | SO16L | SO16L | SO16L | SO6L | SO6L |
BVS (Min) [Vrms] @ t = 60 [s] | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 |
VCC / VDD (Min) [V] | 15 | 15 | 15 | 15.0 | 15 | 15 |
VCC / VDD (Max) [V] | 30 | 30 | 30 | 23.5 | 30 | 30 |
ICC / IDD (Max) [mA] | 3.8 | 5 | 5 | 10.2 | 3 | 3 |
Output Interface | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) |
Example of power supply circuit to analog front end
Part Number | |||||
---|---|---|---|---|---|
Toshiba Package Name | WCSP4F | DFN4F | WCSP4F | SOT-553 (ESV) | SOT-25 (SMV) |
IOUT (Max) [mA] | 500 | 300 | 300 | 200 | 200 |
VOUT [V] | 0.9 to 5.0 | 0.9 to 4.5 | 0.8 to 5.0 | 0.8 to 3.6 | 1.5 to 5.0 |
Example of power supply circuit to main MCU
Part Number | |||||
---|---|---|---|---|---|
Toshiba Package Name | WCSP4F | DFN4F | WCSP4F | SOT-553 (ESV) | SOT-25 (SMV) |
IOUT (Max) [mA] | 500 | 300 | 300 | 200 | 200 |
VOUT [V] | 0.9 to 5.0 | 0.9 to 4.5 | 0.8 to 5.0 | 0.8 to 3.6 | 1.5 to 5.0 |
Example of power supply circuit to communication MCU
Part Number | |||||
---|---|---|---|---|---|
Toshiba Package Name | WCSP4F | DFN4F | WCSP4F | SOT-553 (ESV) | SOT-25 (SMV) |
IOUT (Max) [mA] | 500 | 300 | 300 | 200 | 200 |
VOUT [V] | 0.9 to 5.0 | 0.9 to 4.5 | 0.8 to 5.0 | 0.8 to 3.6 | 1.5 to 5.0 |
Example of AC-DC converter (with PFC circuit) and control circuit
Part Number | ||||
---|---|---|---|---|
Toshiba Package Name | TO-247 | TO-247 | TO-247-4L(X) | TO-247-4L(X) |
VDSS (Max) [V] | 650 | 1200 | 650 | 1200 |
ID (Max) [A] | 100 | 100 | 100 | 100 |
RDS(ON) (Max) [Ω] @ |VGS| = 18.0 [V] | 0.021 | 0.02 | 0.022 | 0.021 |
Polarity | N-ch | N-ch | N-ch | N-ch |
Part Number | ||||||
---|---|---|---|---|---|---|
Toshiba Package Name | SO16L | SO16L | SO16L | SO16L | SO6L | SO6L |
BVS (Min) [Vrms] @ t = 60 [s] | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 |
VCC / VDD (Min) [V] | 15 | 15 | 15 | 15.0 | 15 | 15 |
VCC / VDD (Max) [V] | 30 | 30 | 30 | 23.5 | 30 | 30 |
ICC / IDD (Max) [mA] | 3.8 | 5 | 5 | 10.2 | 3 | 3 |
Output Interface | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) |
Example of power supply circuit to main MCU
Part Number | |||||
---|---|---|---|---|---|
Toshiba Package Name | WCSP4F | DFN4F | WCSP4F | SOT-553 (ESV) | SOT-25 (SMV) |
IOUT (Max) [mA] | 500 | 300 | 300 | 200 | 200 |
VOUT [V] | 0.9 to 5.0 | 0.9 to 4.5 | 0.8 to 5.0 | 0.8 to 3.6 | 1.5 to 5.0 |
Example of DC-AC inverter and control circuit
Part Number | ||||
---|---|---|---|---|
Toshiba Package Name | TO-247 | TO-247 | TO-247-4L(X) | TO-247-4L(X) |
VDSS (Max) [V] | 650 | 1200 | 650 | 1200 |
ID (Max) [A] | 100 | 100 | 100 | 100 |
RDS(ON) (Max) [Ω] @ |VGS| = 18.0 [V] | 0.021 | 0.02 | 0.022 | 0.021 |
Polarity | N-ch | N-ch | N-ch | N-ch |
Part Number | ||||||
---|---|---|---|---|---|---|
Toshiba Package Name | SO16L | SO16L | SO16L | SO16L | SO6L | SO6L |
BVS (Min) [Vrms] @ t = 60 [s] | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 |
VCC / VDD (Min) [V] | 15 | 15 | 15 | 15.0 | 15 | 15 |
VCC / VDD (Max) [V] | 30 | 30 | 30 | 23.5 | 30 | 30 |
ICC / IDD (Max) [mA] | 3.8 | 5 | 5 | 10.2 | 3 | 3 |
Output Interface | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) | totem-pole(BUF) |
Example of power supply circuit to main MCU
Part Number | ||||
---|---|---|---|---|
Toshiba Package Name | WCSP6F |
