Cordless Cleaner

Overall block diagram

Cordless Cleaner

Click the area you want to check the details in the overall block diagram. Show links to our proposed sub-block diagram.

Main motor drive circuit

Main motor drive circuit (1)

Example of main motor drive circuit using MOSFET

Main motor drive circuit (2)

Example of main motor drive circuit using MOSFET

Head motor drive circuit

Example of head motor drive circuit using MOSFET

LED drive circuit for lighting

Example of LED drive circuit using bipolar transistor

Flyback AC-DC circuits

Example of AC-DC flyback power supply circuit

Main control circuit

Example of main control circuit using MCU

Sub block diagram

Main motor drive circuit

Main motor drive circuit (1)

Example of main motor drive circuit using MOSFET

U-MOS Series N-ch MOSFET (1)
U-MOS Series N-ch MOSFET (2)
Schottky barrier diode
CMOS operational amplifier
MCU

Low on-resistance products are available in the lineup. Improvement of trade-off characteristics between on-resistance and capacitance contributes to energy saving.

Part Number	TPH7R006PL	TPH4R008QM	TPH2R408QM
Toshiba Package Name	SOP Advance	SOP Advance(N)	SOP Advance
V_DSS (Max) [V]	60	80	80
I_D (Max) [A]	79	86	120
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.007	0.004	0.00243
Polarity	N-ch	N-ch	N-ch

Search for lineup

Low on-resistance products are available in the lineup. Improvement of trade-off characteristics between on-resistance and capacitance contributes to energy saving.

Part Number	TPN7R006PL	TPN8R408QM	TK5R1P08QM	TK6R9P08QM
Toshiba Package Name	TSON Advance	TSON Advance	DPAK	DPAK
V_DSS (Max) [V]	60	80	80	80
I_D (Max) [A]	76	32	84	62
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.007	0.0084	0.0051	0.0069
Polarity	N-ch	N-ch	N-ch	N-ch

Search for lineup

We offer a wide lineup of products, featuring small size surface mount type packages suitable for high density mounting.

Part Number	CMS05	CMS15
Toshiba Package Name	M-FLAT	M-FLAT
V_RRM (Max) [V]	30	60
V_R (Max) [V]
C_T (Typ.) [pF]

Search for lineup

Compared to bipolar types, it features lower operating voltage and lower current consumption, contributing to flexibility in equipment design and reduced power loss.

Part Number	TC75S55F	TC75S55FU
Toshiba Package Name	SOT-25 (SMV)	SOT-353 (USV)
V_CC (Max) [V]	7	7
V_CC, V_EE (Max) [V]	+/-3.5	+/-3.5

Search for lineup

System cost reduction, higher efficiency and less development work.

Series	TXZ+^TM 4A Series	TX04 Series	TX03 Series
Group	M4K Group	M470 Group	M370 Group

Search for lineup

Main motor drive circuit (2)

Example of main motor drive circuit using MOSFET

Electronic Fuse (eFuse IC)
N-ch MOSFET gate driver IC (1)
N-ch MOSFET gate driver IC (2)

Electronic fuse (eFuse IC) can be used repeatedly to protect circuits from abnormal conditions such as over current and over voltage.

Part Number	TCKE8 Series	TCKE7 Series	TCKE9 Series	TCKE6 Series
Toshiba Package Name	WSON10B	WSON10	WSON8	TSOP6F
V_IN [V]	4.4 to 18	4.4 to 13.2	2.7 to 23	4.4 to 30
R_ON (Typ.) [mΩ]	28	53	34	52

Search for lineup

It is N-ch MOSFET gate driver IC with Over Voltage Protection function. It contributes to reduction of power consumption and miniaturization of load switch circuit.

Part Number	TCK401G	TCK402G	TCK420G	TCK421G	TCK422G
Toshiba Package Name	WCSP6E	WCSP6E	WCSP6G	WCSP6G	WCSP6G
V_{OVL_FA} (Typ.) [V]			27.56	23.14	14.17
V_{OVL_RI} (Typ.) [V]			27.73	23.26	14.29
V_GS (Typ.) [V]	8.5	8.5	10	10	10

Search for lineup

It is N-ch MOSFET gate driver IC with Over Voltage Protection function. It contributes to reduction of power consumption and miniaturization of load switch circuit.

Part Number	TCK423G	TCK424G	TCK425G
Toshiba Package Name	WCSP6G	WCSP6G	WCSP6G
V_{OVL_FA} (Typ.) [V]	14.17	10.71	6.19
V_{OVL_RI} (Typ.) [V]	14.29	10.83	6.31
V_GS (Typ.) [V]	5.6	5.6	5.6

Search for lineup

Head motor drive circuit

Example of head motor drive circuit using MOSFET

U-MOS Series P-ch MOSFET
Schottky barrier diode
CMOS operational amplifier
MCU

Low on-resistance products are available in the lineup. Improvement of trade-off characteristics between on-resistance and capacitance contributes to energy saving.

Part Number	TPCA8120
Toshiba Package Name	SOP Advance
V_DSS (Max) [V]	-30
I_D (Max) [A]	-45
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.003
Polarity	P-ch

Search for lineup

We offer a wide lineup of products, featuring small size surface mount type packages suitable for high density mounting.

Part Number	CMS05	CMS15
Toshiba Package Name	M-FLAT	M-FLAT
V_RRM (Max) [V]	30	60
V_R (Max) [V]
C_T (Typ.) [pF]

Search for lineup

Compared to bipolar types, it features lower operating voltage and lower current consumption, contributing to flexibility in equipment design and reduced power loss.

Part Number	TC75S55F	TC75S55FU
Toshiba Package Name	SOT-25 (SMV)	SOT-353 (USV)
V_CC (Max) [V]	7	7
V_CC, V_EE (Max) [V]	+/-3.5	+/-3.5

Search for lineup

System cost reduction, higher efficiency and less development work.

Series	TXZ+^TM 4A Series	TX04 Series	TX03 Series
Group	M4K Group	M470 Group	M370 Group

Search for lineup

LED drive circuit for lighting

Example of LED drive circuit using bipolar transistor

Small surface mount bipolar transistor (1)
Small surface mount bipolar transistor (2)
MCU

Through our extensive product lineup, we provide products that meet the needs of customers.

Part Number	2SC2712	TBC847	2SA1162	TBC857
Toshiba Package Name	SOT-346 (S-Mini)	SOT-23 (SOT23)	SOT-346 (S-Mini)	SOT-23 (SOT23)
V_CEO (Max) [V]	50	50	-50	-50
I_C (Max) [A]	0.15	0.15	-0.15	-0.15
Polarity	NPN	NPN	PNP	PNP

Search for lineup

Through our extensive product lineup, we provide products that meet the needs of customers.

Part Number	HN1B01FU
Toshiba Package Name	SOT-363 (US6)
V_CEO (Q1) (Max) [V]	-50
V_CEO (Q2) (Max) [V]	50
I_C (Q1) (Max) [A]	-0.15
I_C (Q2) (Max) [A]	0.15
Polarity (Q1)	PNP
Polarity (Q2)	NPN

Search for lineup

System cost reduction, higher efficiency and less development work.

Series	TXZ+^TM 4A Series	TX04 Series	TX03 Series
Group	M4K Group	M470 Group	M370 Group

Search for lineup

Flyback AC-DC circuits

Example of AC-DC flyback power supply circuit

Transistor output photocoupler

High current transfer ratio (CTR) is realized even in the low input current range (I_F=0.5 mA).

Part Number	TLP383
Toshiba Package Name	4pin SO6L
BV_S (Min) [V_rms] @ t = 60 [s]	5000
V_CEO (Max) [V]	80
T_opr [°C]	-55 to 125

Search for lineup

Main control circuit

Example of main control circuit using MCU

U-MOS Series N-ch MOSFET (1)
U-MOS Series N-ch MOSFET (2)
U-MOS Series P-ch MOSFET
Schottky barrier diode
MCU

Low on-resistance products are available in the lineup. Improvement of trade-off characteristics between on-resistance and capacitance contributes to energy saving.

Part Number	TPH7R006PL	TPH4R008QM	TPH2R408QM
Toshiba Package Name	SOP Advance	SOP Advance(N)	SOP Advance
V_DSS (Max) [V]	60	80	80
I_D (Max) [A]	79	86	120
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.007	0.004	0.00243
Polarity	N-ch	N-ch	N-ch

Search for lineup

Low on-resistance products are available in the lineup. Improvement of trade-off characteristics between on-resistance and capacitance contributes to energy saving.

Part Number	TPN7R006PL	TPN8R408QM	TK5R1P08QM	TK6R9P08QM
Toshiba Package Name	TSON Advance	TSON Advance	DPAK	DPAK
V_DSS (Max) [V]	60	80	80	80
I_D (Max) [A]	76	32	84	62
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.007	0.0084	0.0051	0.0069
Polarity	N-ch	N-ch	N-ch	N-ch

Search for lineup

Low on-resistance products are available in the lineup. Improvement of trade-off characteristics between on-resistance and capacitance contributes to energy saving.

Part Number	TPCA8120
Toshiba Package Name	SOP Advance
V_DSS (Max) [V]	-30
I_D (Max) [A]	-45
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.003
Polarity	P-ch

Search for lineup

We offer a wide lineup of products, featuring small size surface mount type packages suitable for high density mounting.

Part Number	CMS05	CMS15
Toshiba Package Name	M-FLAT	M-FLAT
V_RRM (Max) [V]	30	60
V_R (Max) [V]
C_T (Typ.) [pF]

Search for lineup

System cost reduction, higher efficiency and less development work.

Series	TXZ+^TM 4A Series	TX04 Series	TX03 Series
Group	M4K Group	M470 Group	M370 Group

Search for lineup
