TCR13AGADJ

Application	Mobile equipment / Camera/Sensor power supply / RF power supply
Feature	Low dropout voltage / High ripple rejection ratio / Fast load transient response / Small package
Output Type	Adjustable Output
Overcurrent protection	Y
Thermal shutdown	Y
Auto-discharge	Y
Inrush current reduction	Y
RoHS Compatible Product(s) (#)	Available

Toshiba Package Name	WCSP6F
Package Image
Pins	6
Mounting	Surface Mount
Width×Length×Height (mm)	1.2×0.8×0.33
Package Dimensions	View
Land pattern dimensions	View
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Characteristics	Symbol	Rating	Unit
Input Voltage	V_IN	6	V
Power Dissipation (mounted on glass-epoxy board(40mm×40mm))	P_D	1900	mW

Characteristics	Symbol	Condition	Value	Unit
Operating Output Current (Max)	I_OUT	-	1300	mA
Operating Input Voltage *	V_IN	-	VOUT+0.1V to VBIAS	V
Output Voltage (Adjustable)	V_OUT	-	0.55 to 3.6	V
Quiescent Current (Typ.) *	I_B(ON)	I_OUT=0mA	56	μA
Stand-by Current (Typ.) *	I_B(OFF)	-	0.1	μA
Dropout Voltage (Typ.) *	V_DO	I_OUT=1A	92	mV
Ripple Rejection Ratio (Typ.) *	R.R.	f=1kHz	90	dB
Output Noise Voltage (Typ.) *	V_NO	-	52	μVrms
Operating Temperature	T_opr	-	-40 to 85	℃
Output Capacitance	C_OUT	-	≥4.7	μF

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	Note
TCR13AGADJ,LF	5000		Yes	General Use
