TLP385

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

Site Map

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Feature	2.3mm low-profile package / DC input
Application Scope	Communication interface / PLC / Power supply
Function	General-purpose
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

Package Information

Toshiba Package Name	4pin SO6L
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.84×10.0×2.1
Package Dimensions	View
Land pattern dimensions	View
Ultra Librarian^® CAD model (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note1)(Note3)
SamacSys CAD model (Symbol, Footprint and 3D model)	Download from SamacSys (Note2)(Note3)

Please refer to the link destination to check the detailed size.

(Note1)	Ultra Librarian^® is a Registered trademark and CAD model library of EMA (EMA Design Automation, Inc.). CAD models (Symbol/Footprint /3D model) are provided by UltraLibrarian^®. The footprints are generated based on the specifications of Ultra Librarian^®.
(Note2)	SamacSys is a wholly owned subsidiary of Supplyframe, Inc. CAD models (Symbol/Footprint /3D model) are provided by Supplyframe, Inc. The footprints are generated based on the specifications of SamacSys.
(Note3)	Please note that the footprint dimensions may differ from the reference Land Pattern dimensions provided on our website.

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Collector-emitter voltage	V_CEO	80	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.05	A
Operating Temperature	T_opr	-55 to 110	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.3	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	5000	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=-	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=-	50	%

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

Data sheet TLP385 Data sheet/Japanese

PDF: 952KB

May,2022

Data sheet TLP385 Data sheet/English

PDF: 796KB

May,2022

Simulation Model PSpice Model ZIP

ZIP: 4KB

Jul,2018

Simulation Model LTspice Model (Note) ZIP

ZIP: 8KB

Apr,2025

Reliability Information Reliability Data

PDF: 200KB

Dec,2023

Application Note Safety standards for photocouplers

PDF: 753KB

Mar,2021

Application Note Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Catalog Selection Guide Isolators and Solid State Relays 2025Rev1.0

PDF: 7871KB

Feb,2025

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

(Note)

LTspice ^® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Orderable part number (example)	MOQ(pcs)	RoHS	Current Transfer Ratio (%)	VDE
TLP385(BL-TPL,E	3000	Yes	BL (200%-600%)	-
TLP385(BLL-TPL,E	3000	Yes	BLL(200%-400%)	-
TLP385(D4-GRH,E	125	Yes	GRH(150-300%)	Yes
TLP385(D4-GRL,E	125	Yes	GRL(100-200%)	Yes
TLP385(D4-TPL,E	3000	Yes	-	Yes
TLP385(D4BL-TL,E	3000	Yes	BL (200%-600%)	Yes
TLP385(D4BLLTL,E	3000	Yes	BLL(200%-400%)	Yes
TLP385(D4GB-TL,E	3000	Yes	GB(100%-600%)	Yes
TLP385(D4GH-TL,E	3000	Yes	GRH(150%-300%)	Yes
TLP385(D4GL-TL,E	3000	Yes	GRL(100%-200%)	Yes
TLP385(D4GR-TL,E	3000	Yes	GR(100%-300%)	Yes
TLP385(D4Y-TPL,E	3000	Yes	Y(50%-150%)	Yes
TLP385(D4YH-TL,E	3000	Yes	YH(75%-150%)	Yes
TLP385(GB-TPL,E	3000	Yes	GB(100%-600%)	-
TLP385(GR-TPL,E	3000	Yes	GR(100%-300%)	-
TLP385(GRH-TPL,E	3000	Yes	GRH(150%-300%)	-
TLP385(GRL-TPL,E	3000	Yes	GRL(100%-200%)	-
TLP385(TPL,E	3000	Yes	-	-
TLP385(Y-TPL,E	3000	Yes	Y(50%-150%)	-
TLP385(YH-TPL,E	3000	Yes	YH(75%-150%)	-

Applications

Inverter/Servo

Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.

Details

Air Conditioner

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing air conditioner. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

Details

Washing Machine

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing washing machine. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

Details

Inkjet Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing inkjet printer. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, engine (motor driving) units, scanner unit, etc., along with circuit configuration examples.

Details

Air Cleaner

Such as high efficiency, low power consumption and miniaturization are important in designing air cleaner. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving units, sensor signal input unit, etc., along with circuit configuration examples.

Details

LED lighting

Such as high efficiency, low power consumption and miniaturization are important in designing LED lighting. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, sensor signal input units, etc., along with circuit configuration examples.

Details

Microwave Oven

Such as low noise, low power consumption and miniaturization are important in designing microwave oven. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, magnetron driving circuit units, sensor signal input units, etc., along with circuit configuration examples.

Details

Multi Function Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing multi function printer (MFP). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, engine (motor driving) units, scanner units, control units, etc., along with circuit configuration examples.

Details

Thermostat

Such as low power consumption and miniaturization are important in designing thermostat. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, isolation units, sensor signal input units, etc., along with circuit configuration examples.

Details

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
