TLP5774H

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

Site Map

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Feature	4.0A peak current
Application Scope	Induction cooktop / Inverter / PV inverter
Function	IGBT driver
Number of Circuits	1
Output Interface	totem-pole(BUF)
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

Package Information

Toshiba Package Name	SO6L
Package Image
Pins	6
Mounting	Surface Mount
Width×Length×Height (mm)	3.84×10×2.1
Package Dimensions	View
Land pattern dimensions	View

Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Supply Voltage	V_CC	35	V
Operating Temperature	T_opr	-40 to 125	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Pulse width distortion	\|tpHL-tpLH\|	-	50	ns
Isolation voltage	BV_S	t=60sec	5000	Vrms
Common mode transient immunity	CM_H / CM_L	-	+/-35	kV/μs
I_CC (Max)	I_CC	-	3	mA
threshold input current(L/H)	I_FLH	-	2	mA
Output Current Iout (peak) (Max)	I_OP	-	+/-4.0	A
Propagation delay time (H/L)(Max)	tpHL	-	150	ns
Propagation delay time (L/H)(Max)	tpLH	-	150	ns
Supply Voltage(under Recommended Operating Conditions)(Max)	V_CC	-	30	V
Supply Voltage(under Recommended Operating Conditions)(Min)	V_CC	-	10	V

Applications

Inverter/Servo

Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.

Details

Microwave Oven

Such as low noise, low power consumption and miniaturization are important in designing microwave oven. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, magnetron driving circuit units, sensor signal input units, etc., along with circuit configuration examples.

Details

Mega-solar Inverters

Such as high efficiency and miniaturization are important in designing mega-solar inverter. Toshiba provides information on a wide range of semiconductor products suitable for inverter circuit unit, gate driving circuit unit, signal transmission unit, etc., along with circuit configuration examples.

Details

IH Rice Cooker

Such as high breakdown voltage, low power consumption and miniaturization are important in designing IH rice cooker. Toshiba provides information on a wide range of semiconductor products suitable for IH coil driving units, motor driving units, heater control unit, etc., along with circuit configuration examples.

Details

IH Cooking Heater

Such as high breakdown voltage, low power consumption and miniaturization are important in designing IH cooking heater. Toshiba provides information on a wide range of semiconductor products suitable for IH coil driving units, motor driving units, current detecting unit, etc., along with circuit configuration examples.

Details

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
