TAR5S50U

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

Site Map

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Application	Consumer equipment / General purpose power supply
Feature	Wide range input voltage / Low output noise voltage
Output Type	Fixed Output
Overcurrent protection	Y
Thermal shutdown	Y
RoHS Compatible Product(s) (#)	Available

Part Number	Compatible level	Notes
TCR1HF50B	Different package and similar characteristics	-

Package Information

Toshiba Package Name	SOT-353F (UFV)
Package Image
Package Code	SOT-353F
Pins	5
Mounting	Surface Mount
Width×Length×Height (mm)	2.0×2.1×0.7
Package Dimensions	View
Land pattern dimensions	View
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note)

Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Input Voltage	V_IN	15	V
Power Dissipation (mounted on glass-epoxy board(30mm×30mm))	P_D	450	mW

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Operating Output Current (Max)	I_OUT	-	200	mA
Operating Input Voltage *	V_IN	-	2.4 to 15	V
Output Voltage (Typ.)	V_OUT	-	5.0	V
Output Voltage Lineup	V_OUT	-	1.5 to 5.0	V
Quiescent Current (Typ.) *	I_B(ON)	I_OUT=0mA	170	μA
Dropout Voltage (Typ.) *	V_DO	I_OUT=0.05A	130	mV
Ripple Rejection Ratio (Typ.) *	R.R.	f=1kHz	70	dB
Output Noise Voltage (Typ.) *	V_NO	-	30	μVrms
Operating Temperature	T_opr	-	-40 to 85	℃
Output Capacitance	C_OUT	-	≥10	μF

*: Representative value, Please refer to the datasheet for details.

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
