Description

Description	TLX9188 consists of phototransistors optically coupled to an infrared LED. TLX9188 is housed in the very small and thin SO6(4pin) package and that guarantees high temperature operation(Ta=125 °C max). With the high breakdown voltage between the collector and emitter (VCEO=200 V), TLX9188 is suitable for use in battery management system.
Feature	2.3mm low-profile package / High V_CEO
Application Scope	Various Controllers / Signal transmission between different circuit potential / HEV(Hybrid Electric Vehicle) and EV(Electric Vehicle) Applications
Function	High VCEO
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available

Package Information

Toshiba Package Name	4pin SO6
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.7×7.0×2.1
Package Dimensions	View
Land pattern dimensions	View
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note)

Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Collector-emitter voltage	V_CEO	200	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.03	A
Operating Temperature	T_opr	-40 to 125	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.4	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	3750	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=GB	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=GB	100	%

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

Data sheet TLX9188 Data sheet/Japanese

PDF: 488KB

Sep,2021

Data sheet TLX9188 Data sheet/English

PDF: 599KB

Sep,2021

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 85KB

Dec,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 85KB

Dec,2024

Application Note Safety standards for photocouplers

PDF: 753KB

Mar,2021

Application Note Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Catalog Selection Guide Isolators and Solid State Relays 2024Rev2.0

PDF: 14710KB

Aug,2024

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

Applications

Automotive DC-DC Converter

Such as reduction of power consumption and miniaturization are important in designing DC-DC converter. Toshiba provides information on a wide range of semiconductor products suitable for step-up or step-down DC-DC converter units, etc., along with circuit configuration examples.

Details

Battery Management System for Automotive

Such as reduction of power consumption and miniaturization are important in battery management system. Toshiba provides information on a wide range of semiconductor products suitable for charging circuit, cell balancing circuit, battery monitoring circuit, etc., along with circuit configuration examples.

Details

Automotive On-board Charger

Such as reduction of power consumption and miniaturization of circuit boards are important in designing on-board charger. Toshiba provides information on a wide range of semiconductor products suitable for DC-DC converter units, power supply units, etc., along with circuit configuration examples.

Details
