Description

Description	TLX9188 consists of phototransistors optically coupled to an infrared LED. TLX9188 is housed in the very small and thin SO6(4pin) package and that guarantees high temperature operation(Ta=125 °C max). With the high breakdown voltage between the collector and emitter (VCEO=200 V), TLX9188 is suitable for use in battery management system.
Feature	2.3mm low-profile package / High V_CEO
Application Scope	Various Controllers / Signal transmission between different circuit potential / HEV(Hybrid Electric Vehicle) and EV(Electric Vehicle) Applications
Function	High VCEO
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available

Package Information

Toshiba Package Name	4pin SO6
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.7×7.0×2.1
Package Dimensions	View
Land pattern dimensions	View

Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Collector-emitter voltage	V_CEO	200	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.03	A
Operating Temperature	T_opr	-40 to 125	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.4	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	3750	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=GB	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=GB	100	%
