TLX9188

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

문의

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Description

Description	TLX9188 consists of phototransistors optically coupled to an infrared LED. TLX9188 is housed in the very small and thin SO6(4pin) package and that guarantees high temperature operation(Ta=125 °C max). With the high breakdown voltage between the collector and emitter (VCEO=200 V), TLX9188 is suitable for use in battery management system.
Feature	2.3mm low-profile package / High V_CEO
Application Scope	Various Controllers / Signal transmission between different circuit potential / HEV(Hybrid Electric Vehicle) and EV(Electric Vehicle) Applications
Function	High VCEO
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available

Package Information

Toshiba Package Name	4pin SO6
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.7×7.0×2.1
Package Dimensions	보기
Land pattern dimensions	보기
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note) Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Collector-emitter voltage	V_CEO	200	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.03	A
Operating Temperature	T_opr	-40 to 125	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.4	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	3750	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=GB	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=GB	100	%

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

Data sheet TLX9188 Data sheet/Japanese

PDF: 488KB

Sep,2021

Data sheet TLX9188 Data sheet/English

PDF: 599KB

Sep,2021

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 85KB

Nov,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 85KB

Nov,2024

Application Note Safety standards for photocouplers

PDF: 753KB

Mar,2021

Application Note Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Catalog Selection Guide Isolators and Solid State Relays 2024Rev2.0

PDF: 14710KB

Aug,2024

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

애플리케이션

Automotive DC-DC Converter

Such as reduction of power consumption and miniaturization are important in designing DC-DC converter. Toshiba provides information on a wide range of semiconductor products suitable for step-up or step-down DC-DC converter units, etc., along with circuit configuration examples.

세부 사항

Battery Management System for Automotive

Such as reduction of power consumption and miniaturization are important in battery management system. Toshiba provides information on a wide range of semiconductor products suitable for charging circuit, cell balancing circuit, battery monitoring circuit, etc., along with circuit configuration examples.

세부 사항

Automotive On-board Charger

Such as reduction of power consumption and miniaturization of circuit boards are important in designing on-board charger. Toshiba provides information on a wide range of semiconductor products suitable for DC-DC converter units, power supply units, etc., along with circuit configuration examples.

세부 사항

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
