CUHS15F40

Small-signal Schottky barrier diode

  • Related Reference Design(1)

Data sheet

CUHS15F40 Data sheet/Japanese[Sep,2019]PDF: 359KB

Data sheet

CUHS15F40 Data sheet/English[Sep,2019]PDF: 244KB

Simulation Model

PSpice Model[Jan,2020]lib: 1KB

Reliability Information

Reliability Data[Sep,2024]PDF: 247KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 86KB

Application Note

Thermal Design for Schottky Barrier Diodes (SBDs) in the US2H Package[Dec,2022]PDF: 1729KB

Application Note

Basics of Diodes (Power Losses and Thermal Design)[Aug,2021]PDF: 649KB

Application Note

Basics of Diodes (Absolute Maximum Ratings and Electrical Characteristics)[Aug,2021]PDF: 846KB

Application Note

Basics of Diodes (Types and Overview of Diodes)[Aug,2021]PDF: 1557KB

Application Note

Selecting a Schottky Barrier Diode for Voltage Boost Circuits[Mar,2021]PDF: 625KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction of Toshiba diode lineup for Industries[Apr,2024]PDF: 943KB

Catalog

Mini catalog Toshiba's circuit protection solutions and switch solutions[Aug,2023]PDF: 523KB

Data sheet

CUHS15F40 Data sheet/Japanese[Sep,2019]PDF: 359KB

Data sheet

CUHS15F40 Data sheet/English[Sep,2019]PDF: 244KB

Application Note

Thermal Design for Schottky Barrier Diodes (SBDs) in the US2H Package[Dec,2022]PDF: 1729KB

Application Note

Basics of Diodes (Power Losses and Thermal Design)[Aug,2021]PDF: 649KB

Application Note

Basics of Diodes (Absolute Maximum Ratings and Electrical Characteristics)[Aug,2021]PDF: 846KB

Application Note

Basics of Diodes (Types and Overview of Diodes)[Aug,2021]PDF: 1557KB

Application Note

Selecting a Schottky Barrier Diode for Voltage Boost Circuits[Mar,2021]PDF: 625KB

Simulation Model

PSpice Model[Jan,2020]lib: 1KB

Reliability Information

Reliability Data[Sep,2024]PDF: 247KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 86KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction of Toshiba diode lineup for Industries[Apr,2024]PDF: 943KB

Catalog

Mini catalog Toshiba's circuit protection solutions and switch solutions[Aug,2023]PDF: 523KB

Description

Feature High-speed switching
Internal Connection Single
Number of Circuits 1
RoHS Compatible Product(s) (#) Available

Package Information

Toshiba Package Name SOD-323HE (US2H)
Package Image US2H
Package Code SOD-323HE
Pins 2
Mounting Surface Mount
Width×Length×Height
(mm)		 2.5×1.4×0.60
Package Dimensions 보기
Land pattern dimensions 보기
CAD data
(Symbol, Footprint and 3D model)		 Download from UltraLibrarian<sup>®</sup> in your desired CAD format (Note) Download from UltraLibrarian® in your desired CAD format (Note)

 Please refer to the link destination to check the detailed size.

 (Note) Ultra Librarian® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Average Forward Current IO 1.5 A
Reverse Voltage VR 40 V

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Total Capacitance (Typ.) CT VR=0V
f=1MHz		 130 pF
Forward Voltage (Max) VF IF=500mA 0.45 V
Forward Voltage (Max) VF IF=1000mA 0.54 V
Forward Voltage (Max) VF IF=1500mA 0.63 V
Forward Voltage (Typ.) VF IF=500mA 0.40 V
Forward Voltage (Typ.) VF IF=1000mA 0.49 V
Forward Voltage (Typ.) VF IF=1500mA 0.57 V
Reverse Current (Max) IR VR=40V 0.05 mA
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.

Document

  • If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Jan,2020

Sep,2024

Nov,2024

Nov,2024

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS Note
CUHS15F40,H3F 3000 Yes General Use

애플리케이션

Electronic Sphygmomanometer
Such as low power consumption and miniaturization are important in designing electronic sphygmomanometer. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, surge voltage protection units, motor driving units, sensor signal input units, etc., along with circuit configuration examples.
