Photocouplers for IPM Interface

This photocoupler supports power supply voltages of 5 V and 15 V, whichever is best suited as an insulated interface for IPM (Intelligent Power Module). The output circuit lineup includes an open collector circuit and a totem pole circuit. In addition, the two types of totem pole circuit components, inverter logic output and buffer logic output, can be selected according to the input circuit of each company's IPM, such as High Active and Low Active.

Lineup

You can narrow down the search for applicable products by selecting specifications.

Data transfer rate (Mbps)
Output Interface
VCC/VDD (Min) (V)
VCC/VDD (Max) (V)
BVS (Min) (Vrms)
Results:

You can narrow down your search for applicable products by package type or number of pins.

unit:
5pin SO6

Package Size

W : 3.7 mm 0.15 inch
L : 7.0 mm 0.28 inch
H : 2.1 mm 0.083 inch
SO6L

Package Size

W : 3.84 mm 0.15 inch
L : 10 mm 0.39 inch
H : 2.1 mm 0.083 inch

All package dimensions are guaranteed in millimeters as mentioned on datasheet. Package dimension in inches is round to 2 significant digits converted with 1mm=0.0393701inch.

3글자 이상 입력하세요.

About information presented in this cross reference

The information presented in this cross reference is based on TOSHIBA's selection criteria and should be treated as a suggestion only. Please carefully review the latest versions of all relevant information on the TOSHIBA products, including without limitation data sheets and validate all operating parameters of the TOSHIBA products to ensure that the suggested TOSHIBA products are truly compatible with your design and application.
Please note that this cross reference is based on TOSHIBA's estimate of compatibility with other manufacturers' products, based on other manufacturers' published data, at the time the data was collected.
TOSHIBA is not responsible for any incorrect or incomplete information. Information is subject to change at any time without notice.

Technical Articles

Isolators/Solid State Relays / Photocouplers / Photocouplers for IPM Interface

Support for high active and low active IPM
Our photocouplers for IPM interfaces are aligned with buffer output (output signal High with LED signal ON) for high active IPM, and inverter output (output Low with LED signal ON) for low active IPM.

Isolators/Solid State Relays / Photocouplers / Photocouplers for IPM Interface

Higher common-mode transient immunity (CMTI)
In order to ensure stable operation even when a large dV/dt is applied between the input and output of the photocoupler when the IPM is switched, the photo IC chip has a shield.

Isolators/Solid State Relays / Photocouplers / Photocouplers for IPM Interface

Response to higher speeds
The photocoupler for the IPM interface guarantees the maximum propagation delay time and enables high-speed transmission of PWM signals.

Documents

Name Date

애플리케이션

Inverter/Servo
Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.
세부 사항
Mega-solar Inverters
Such as high efficiency and miniaturization are important in designing mega-solar inverter. Toshiba provides information on a wide range of semiconductor products suitable for inverter circuit unit, gate driving circuit unit, signal transmission unit, etc., along with circuit configuration examples.
세부 사항
