DF2B5M4ASL

ESD protection diode (bi-directional type)

Data sheet

DF2B5M4ASL Data sheet/Japanese[Aug,2019]PDF: 499KB

Data sheet

DF2B5M4ASL Data sheet/English[Aug,2019]PDF: 368KB

Simulation Model

PSpice Model[Mar,2020]lib: 1KB

Reliability Information

Reliability Data[Sep,2024]PDF: 276KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 87KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 87KB

Application Note

Basics of ESD Protection (TVS)Diodes[May,2022]PDF: 1674KB

Application Note

Overvoltage protection device Zener diode and ESD protection diode[Apr,2022]PDF: 1161KB

Application Note

Basics of Diodes (Power Losses and Thermal Design)[Aug,2021]PDF: 649KB

Application Note

Basics of Diodes (Absolute Maximum Ratings and Electrical Characteristics)[Aug,2021]PDF: 846KB

Application Note

Basics of Diodes (Types and Overview of Diodes)[Aug,2021]PDF: 1557KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction of Toshiba TVS Diodes(ESD Protection Diodes) Line-up[Jul,2024]PDF: 575KB

Catalog

Mini catalog Introduction of Toshiba Zener Diode for protection[Jul,2024]PDF: 541KB

Catalog

Mini catalog Introduction of Toshiba diode lineup for Industries[Apr,2024]PDF: 943KB

Catalog

Mini catalog Toshiba's circuit protection solutions and switch solutions[Aug,2023]PDF: 523KB

Data sheet

DF2B5M4ASL Data sheet/Japanese[Aug,2019]PDF: 499KB

Data sheet

DF2B5M4ASL Data sheet/English[Aug,2019]PDF: 368KB

Application Note

Basics of ESD Protection (TVS)Diodes[May,2022]PDF: 1674KB

Application Note

Overvoltage protection device Zener diode and ESD protection diode[Apr,2022]PDF: 1161KB

Application Note

Basics of Diodes (Power Losses and Thermal Design)[Aug,2021]PDF: 649KB

Application Note

Basics of Diodes (Absolute Maximum Ratings and Electrical Characteristics)[Aug,2021]PDF: 846KB

Application Note

Basics of Diodes (Types and Overview of Diodes)[Aug,2021]PDF: 1557KB

Simulation Model

PSpice Model[Mar,2020]lib: 1KB

Reliability Information

Reliability Data[Sep,2024]PDF: 276KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 87KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 87KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction of Toshiba TVS Diodes(ESD Protection Diodes) Line-up[Jul,2024]PDF: 575KB

Catalog

Mini catalog Introduction of Toshiba Zener Diode for protection[Jul,2024]PDF: 541KB

Catalog

Mini catalog Introduction of Toshiba diode lineup for Industries[Apr,2024]PDF: 943KB

Catalog

Mini catalog Toshiba's circuit protection solutions and switch solutions[Aug,2023]PDF: 523KB

Description

Internal Connection Single
Number of Circuits 1
Number of Protected Lines 1
Configuration Bidirectional
Application USB3.1 / HDMI2.0 / Thunderbolt / RF ant.
RoHS Compatible Product(s) (#) Available

Package Information

package name (TOSHIBA) SOD-962 (SL2)
Package Image SL2
package code SOD-962
Pins 2
Mounting Surface Mount
Width×Length×Height
(mm)		 0.62×0.32×0.3
Package Dimensions 보기
Land pattern dimensions 보기
CAD data
(Symbol, Footprint and 3D model)		 Download from UltraLibrarian<sup>®</sup> in your desired CAD format (Note) Download from UltraLibrarian® in your desired CAD format (Note)

 Please refer to the link destination to check the detailed size.

 (Note) Ultra Librarian® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Electrostatic discharge voltage(IEC61000-4-2) VESD +/-16 kV
Peak pulse current (IEC61000-4-5) IPP 2 A

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Working peak reverse voltage (Max) VRWM - +/-3.6 V
Total Capacitance (Max) CT VR=0V
f=1MHz		 0.2 pF
Total Capacitance (Typ.) CT VR=0V
f=1MHz		 0.15 pF
Dynamic resistance (Typ.) Rdyn IPP=8A to 16A 0.7 Ω
Reverse Current (Max) IR VRWM=3.6V 0.1 μA
Clamp voltage (Based on IEC61000-4-5) (Typ.) VC IPP=1A 7.7 V
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.

Document

  • If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Mar,2020

Sep,2024

Nov,2024

Nov,2024

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS Note
DF2B5M4ASL,L3F 10000 Yes General Use
