TPD7212FN

Description

Application Scope	Motor drivers
Input / Output	H/H
Input / Output (Q1)	H/H
Input / Output (Q2)	H/H
Number of Circuits	6
Diagnostic Functions	Voltage monitor of output / V_DH undervoltage detection / V_DL undervoltage detection / V_DL overvoltage detection
Protection Functions	Short through current / Voltage monitor of output
PPAP	Capable(*)
AEC-Q100	Qualified(*)
RoHS Compatible Product(s) (#)	Available

*: For detail information, please contact to our sales.

Package Information

Toshiba Package Name	SSOP30
Package Image
Pins	30
Mounting	Surface Mount
Width×Length×Height (mm)	10.2×7.6×1.2
Package Dimensions	보기

Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Output Current	I_O	+1.5/-1	A
Power Dissipation	P_D	2.6	W
Junction temperature	T_j	175	℃
Operating Temperature (Max)	T_opr	150	℃
Operating Temperature (Min)	T_opr	-40	℃
Input Voltage (Max)	V_IN	6	V
Input Voltage (Min)	V_IN	-0.3	V
Power Supply Voltage (Max)	V_DD	25	V

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
ON Resistance (Max)	R_DS(ON)	-	3.0/2.0	Ω
Operating Supply Voltage (Max)	V_DD(opr)	-	18	V
Operating Supply Voltage (Min)	V_DD(opr)	-	4.5	V
