TLP383

Description

Feature	2.3mm low-profile package / DC input
Application Scope	Communication interface / PLC / Power supply
Function	Low IF
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

Package Information

Toshiba Package Name	4pin SO6L
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.84×10.0×2.1
Package Dimensions	View
Land pattern dimensions	View
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note) Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Collector-emitter voltage	V_CEO	80	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.05	A
Operating Temperature	T_opr	-55 to 125	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.3	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	5000	Vrms
Current Transfer Ratio (Max)	CTR	I_F=0.5mA V_CE=5V rank=-	600	%
Current Transfer Ratio (Min)	CTR	I_F=0.5mA V_CE=5V rank=-	50	%

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

Data sheet TLP383 Data sheet/Japanese

PDF: 1110KB

May,2022

Data sheet TLP383 Data sheet/English

PDF: 962KB

May,2022

Simulation Model PSpice Model ZIP

ZIP: 4KB

May,2018

Reliability Information Reliability Data

PDF: 203KB

Dec,2023

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 85KB

Nov,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 84KB

Nov,2024

Application Note Safety standards for photocouplers

PDF: 753KB

Mar,2021

Application Note Low-IF couplers-basic properties and application design

PDF: 1950KB

May,2019

Application Note Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Application Note Application note for phototransistor coupler

PDF: 846KB

Feb,2018

Catalog Selection Guide Isolators and Solid State Relays 2024Rev2.0

PDF: 14710KB

Aug,2024

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

Orderable part number

Orderable part number (example)	MOQ(pcs)	RoHS	Current Transfer Ratio (%)	VDE
TLP383(BL-TPL,E	3000	Yes	BL (200%-600%)	-
TLP383(BLL-TPL,E	3000	Yes	BLL(200%-400%)	-
TLP383(D4-TPL,E	3000	Yes	-	Yes
TLP383(D4BL-TL,E	3000	Yes	BL (200%-600%)	Yes
TLP383(D4BLLTL,E	3000	Yes	BLL(200%-400%)	Yes
TLP383(D4GB-TL,E	3000	Yes	GB(100%-600%)	Yes
TLP383(D4GH-TL,E	3000	Yes	GRH(150%-300%)	Yes
TLP383(D4GL-TL,E	3000	Yes	GRL(100%-200%)	Yes
TLP383(D4GR-TL,E	3000	Yes	GR(100%-300%)	Yes
TLP383(D4Y-TL,E	3000	Yes	Y(50%-150%)	Yes
TLP383(D4YH-TL,E	3000	Yes	YH(75%-150%)	Yes
TLP383(GB-TPL,E	3000	Yes	GB(100%-600%)	-
TLP383(GR-TPL,E	3000	Yes	GR(100%-300%)	-
TLP383(GRH-TPL,E	3000	Yes	GRH(150%-300%)	-
TLP383(GRL-TPL,E	3000	Yes	GRL(100%-200%)	-
TLP383(Y-TPL,E	3000	Yes	Y(50%-150%)	-
TLP383(YH-TPL,E	3000	Yes	YH(75%-150%)	-
