TLP383

產品概要

Feature	2.3mm low-profile package / DC input
Application Scope	Communication interface / PLC / Power supply
Function	Low IF
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

包裝資訊

Toshiba Package Name	4pin SO6L
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.84×10.0×2.1
Package Dimensions	檢視
Land pattern dimensions	檢視
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note)

Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

絕對最大額定值

項目	符號	值	單位
Collector-emitter voltage	V_CEO	80	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.05	A
Operating Temperature	T_opr	-55 to 125	℃

電器特性

項目	符號	條件	值	單位
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.3	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	5000	Vrms
Current Transfer Ratio (Max)	CTR	I_F=0.5mA V_CE=5V rank=-	600	%
Current Transfer Ratio (Min)	CTR	I_F=0.5mA V_CE=5V rank=-	50	%

文檔

全部選擇
如果沒看到確認框則對應文件目前無法下載

數據表 TLP383 數據表/日文

PDF: 1110KB

May,2022

數據表 TLP383 數據表/英文

PDF: 962KB

May,2022

Simulation Model PSpice Model ZIP

ZIP: 4KB

May,2018

Reliability Information Reliability Data

PDF: 203KB

Dec,2023

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 85KB

Dec,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 84KB

Dec,2024

Application Note Safety standards for photocouplers

PDF: 753KB

Mar,2021

Application Note Low-IF couplers-basic properties and application design

PDF: 1950KB

May,2019

Application Note Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Application Note Application note for phototransistor coupler

PDF: 846KB

Feb,2018

Catalog Selection Guide Isolators and Solid State Relays 2024Rev2.0

PDF: 14710KB

Aug,2024

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

Orderable part number

Orderable part number (example)	MOQ(pcs)	RoHS	Current Transfer Ratio (%)	VDE
TLP383(BL-TPL,E	3000	Yes	BL (200%-600%)	-
TLP383(BLL-TPL,E	3000	Yes	BLL(200%-400%)	-
TLP383(D4-TPL,E	3000	Yes	-	Yes
TLP383(D4BL-TL,E	3000	Yes	BL (200%-600%)	Yes
TLP383(D4BLLTL,E	3000	Yes	BLL(200%-400%)	Yes
TLP383(D4GB-TL,E	3000	Yes	GB(100%-600%)	Yes
TLP383(D4GH-TL,E	3000	Yes	GRH(150%-300%)	Yes
TLP383(D4GL-TL,E	3000	Yes	GRL(100%-200%)	Yes
TLP383(D4GR-TL,E	3000	Yes	GR(100%-300%)	Yes
TLP383(D4Y-TL,E	3000	Yes	Y(50%-150%)	Yes
TLP383(D4YH-TL,E	3000	Yes	YH(75%-150%)	Yes
TLP383(GB-TPL,E	3000	Yes	GB(100%-600%)	-
TLP383(GR-TPL,E	3000	Yes	GR(100%-300%)	-
TLP383(GRH-TPL,E	3000	Yes	GRH(150%-300%)	-
TLP383(GRL-TPL,E	3000	Yes	GRL(100%-200%)	-
TLP383(Y-TPL,E	3000	Yes	Y(50%-150%)	-
TLP383(YH-TPL,E	3000	Yes	YH(75%-150%)	-

應用

Inverter/Servo

Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.

詳細資料

Air Conditioner

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing air conditioner. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

詳細資料

Robot Cleaner

Such as high efficiency, low power consumption and miniaturization are important in designing robot cleaner. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving units, sensor signal input unit, etc., along with circuit configuration examples.

詳細資料

Warm Water Bidet

Such as high efficiency, low power consumption and miniaturization are important in designing warm water bidet. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving units, etc., along with circuit configuration examples.

詳細資料

Cordless Cleaner

Such as high efficiency, low power consumption and miniaturization are important in designing cordless cleaner. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, control unit, motor driving units, etc., along with circuit configuration examples.

詳細資料

Thermostat

Such as low power consumption and miniaturization are important in designing thermostat. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, isolation units, sensor signal input units, etc., along with circuit configuration examples.

詳細資料

Washing Machine

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing washing machine. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

詳細資料

Server

Such as low power consumption and miniaturization are important in designing server. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, motor driving unit, over temperature monitoring unit, etc., along with circuit configuration examples.

詳細資料

Air Cleaner

Such as high efficiency, low power consumption and miniaturization are important in designing air cleaner. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving units, sensor signal input unit, etc., along with circuit configuration examples.

詳細資料

Inkjet Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing inkjet printer. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, engine (motor driving) units, scanner unit, etc., along with circuit configuration examples.

詳細資料

Multi Function Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing multi function printer (MFP). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, engine (motor driving) units, scanner units, control units, etc., along with circuit configuration examples.

詳細資料

Microwave Oven

Such as low noise, low power consumption and miniaturization are important in designing microwave oven. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, magnetron driving circuit units, sensor signal input units, etc., along with circuit configuration examples.

詳細資料

LED lighting

Such as high efficiency, low power consumption and miniaturization are important in designing LED lighting. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, sensor signal input units, etc., along with circuit configuration examples.

詳細資料

Programmable Logic Controller

Such as high functionality, low power consumption and miniaturization are important in designing programmable
logic controller (PLC). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, input and output module units, control signal transmission units, etc., along with circuit configuration examples.

詳細資料

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
