SSM3J66MFV

Application Scope	Power Management Switches
Feature	1.2-volt gate drive voltage
Polarity	P-ch
Generation	U-MOSⅥ
Internal Connection	Single
PPAP	Capable(*)
AEC-Q101	Qualified(*)
RoHS Compatible Product(s) (#)	Available

Toshiba Package Name	SOT-723 (VESM)
Package Image
JEITA	SC-105AA
Package Code	SOT-723
Pins	3
Mounting	Surface Mount
Width×Length×Height (mm)	1.2×1.2×0.5
Package Dimensions	View
Land pattern dimensions	View
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Characteristics	Symbol	Rating	Unit
Drain-Source voltage	V_DSS	-20	V
Gate-Source voltage	V_GSS	+6/-8	V
Drain current	I_D	-800	mA
Power Dissipation	P_D	0.15	W

Characteristics	Symbol	Condition	Value	Unit
Gate threshold voltage (Max)	V_th	-	-1.0	V
Gate threshold voltage (Min)	V_th	-	-0.3	V
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=4.5V	390	mΩ
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=2.5V	480	mΩ
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=1.8V	660	mΩ
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=1.5V	900	mΩ
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=1.2V	4.0	Ω
Input capacitance (Typ.)	C_iss	-	100	pF
Total gate charge (Typ.)	Q_g	V_GS=-4.5V	1.6	nC
