TLP5214A

Photocoupler (photo-IC output)

  • Related Reference Design(2)

Data sheet

TLP5214A Data sheet/Japanese[Oct,2019]PDF: 1435KB

Data sheet

TLP5214A Data sheet/English[Oct,2019]PDF: 1448KB

Simulation Model

PSpice Model[Dec,2023]ZIP: 19KB

Reliability Information

Reliability Data[Dec,2023]PDF: 201KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 85KB

Application Note

Smart Gate Driver Coupler Tips for Designing DESAT Detection Circuits[May,2022]PDF: 1055KB

Application Note

Smart Gate Driver TLP5214A/TLP5214/TLP5212/TLP5222 Application Note -Introduction-[Apr,2022]PDF: 1534KB

Application Note

Smart Gate Driver Coupler TLP5214/TLP5214A/TLP5212/TLP5222 Appication Note -Advanced edition-[Apr,2022]PDF: 2189KB

Application Note

Safety standards for photocouplers[Mar,2021]PDF: 753KB

Application Note

Gate Drive Coupler Notes on using power device gate negative bias power supply[Jan,2021]PDF: 1030KB

Application Note

Glossary of Photocoupler and Photorelay Terms[Mar,2018]PDF: 509KB

Catalog

Selection Guide Isolators and Solid State Relays 2024Rev2.0[Aug,2024]PDF: 14710KB

Catalog

Photocouplers and Photorelays[Apr,2020]PDF: 2619KB

Data sheet

TLP5214A Data sheet/Japanese[Oct,2019]PDF: 1435KB

Data sheet

TLP5214A Data sheet/English[Oct,2019]PDF: 1448KB

Application Note

Smart Gate Driver Coupler Tips for Designing DESAT Detection Circuits[May,2022]PDF: 1055KB

Application Note

Smart Gate Driver TLP5214A/TLP5214/TLP5212/TLP5222 Application Note -Introduction-[Apr,2022]PDF: 1534KB

Application Note

Smart Gate Driver Coupler TLP5214/TLP5214A/TLP5212/TLP5222 Appication Note -Advanced edition-[Apr,2022]PDF: 2189KB

Application Note

Safety standards for photocouplers[Mar,2021]PDF: 753KB

Application Note

Gate Drive Coupler Notes on using power device gate negative bias power supply[Jan,2021]PDF: 1030KB

Application Note

Glossary of Photocoupler and Photorelay Terms[Mar,2018]PDF: 509KB

Simulation Model

PSpice Model[Dec,2023]ZIP: 19KB

Reliability Information

Reliability Data[Dec,2023]PDF: 201KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 85KB

Catalog

Selection Guide Isolators and Solid State Relays 2024Rev2.0[Aug,2024]PDF: 14710KB

Catalog

Photocouplers and Photorelays[Apr,2020]PDF: 2619KB

Description

Feature 2.3mm low-profile package / Creepage and clearance 8mm / High temperature 110 degC operation
Application Scope Factory automation / Inverter / PV inverter
Function IGBT driver
Number of Circuits 1
Output Interface totem-pole(BUF)
RoHS Compatible Product(s) (#) Available
Safety Standard Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC)

*Download Online Certification of Safety Standard(UL 1577)
*Download Online Certification of Safety Standard(cUL)

Package Information

Toshiba Package Name SO16L
Package Image SO16L
Pins 16
Mounting Surface Mount
Width×Length×Height
(mm)		 10.3×10.0×2.1
Package Dimensions 보기
Land pattern dimensions 보기
CAD data
(Symbol, Footprint and 3D model)		 Download from UltraLibrarian<sup>®</sup> in your desired CAD format (Note)

Download from UltraLibrarian® in your desired CAD format (Note)

 Please refer to the link destination to check the detailed size.

(Note)

Ultra Librarian® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Supply Voltage VCC -0.5 to 35 V
Operating Temperature Topr -40 to 110 ℃

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Pulse width distortion |tpHL-tpLH| - 50 ns
Isolation voltage BVS t=60sec 5000 Vrms
Common mode transient immunity CMH / CML - +/-35 kV/μs
ICC (Max) ICC - 3.8 mA
threshold input current(L/H) IFLH - 6 mA
Output Current Iout (peak) (Max) IOP - +/-4.0 A
Propagation delay time (H/L)(Max) tpHL - 150 ns
Propagation delay time (L/H)(Max) tpLH - 150 ns
Supply Voltage(under Recommended Operating Conditions)(Max) VCC - 30 V
Supply Voltage(under Recommended Operating Conditions)(Min) VCC - 15 V
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.

Document

  • If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Dec,2023

Dec,2023

Dec,2024

Dec,2024

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS
TLP5214A(D4-TP,E 1500 Yes
TLP5214A(TP,E 1500 Yes

Reference Design

Inverter application example of smart gate driver coupler TLP5214A inverter application.
Smart Gate Driver Coupler TLP5214A Inverter Application
This reference design provides example circuits, design guide of built-in functions and thermal design guide for applying TLP5214A to inverter circuit as gate driver.
세부 사항
Photo of evaluation board of Smart Gate Driver Coupler.
Evaluation Board of Smart Gate Driver Coupler
This reference design provides design guide, data and other contents of the evaluation board of Smart Gate Driver Coupler.
세부 사항

애플리케이션

Inverter/Servo
Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.
세부 사항
PV Inverter for Household Use
Such as high efficiency and miniaturization are important in designing PV inverter for household use. Toshiba provides information on a wide range of semiconductor products suitable for convertercircuit unit, inverter circuit unit, etc., along with circuit configuration examples.
세부 사항
Uninterruptible power supply
Such as low power consumption and miniaturization are important in designing uninterruptible power supply (UPS). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, inverter/converter units, control units, signal transmission units, etc., along with circuit configuration examples.
