XPQ1R00AQB

Power MOSFET (N-ch single 60V<VDSS≤150V)

Data sheet

XPQ1R00AQB Data sheet/Japanese[Jun,2023]PDF: 750KB

Data sheet

XPQ1R00AQB Data sheet/English[Jun,2023]PDF: 647KB

Simulation Model

PSpice Model[Jun,2023]ZIP: 42KB

Simulation Model

LTspice Model[Jul,2023]ZIP: 49KB

Simulation Model

SIMetrix Model[Aug,2024]ZIP: 9KB

Simulation Model

ELDO Model[Aug,2024]ZIP: 11KB

Thermal Simulation Model

Simplified CFD Model[Aug,2023]ZIP: 8KB

Reliability Information

Reliability Data[Dec,2024]PDF: 274KB

Application Note

Automotive Discrete Semiconductor MBD Introductory Application Note[Mar,2024]PDF: 1522KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Data sheet

XPQ1R00AQB Data sheet/Japanese[Jun,2023]PDF: 750KB

Data sheet

XPQ1R00AQB Data sheet/English[Jun,2023]PDF: 647KB

Application Note

Automotive Discrete Semiconductor MBD Introductory Application Note[Mar,2024]PDF: 1522KB

Simulation Model

PSpice Model[Jun,2023]ZIP: 42KB

Simulation Model

LTspice Model[Jul,2023]ZIP: 49KB

Simulation Model

SIMetrix Model[Aug,2024]ZIP: 9KB

Simulation Model

ELDO Model[Aug,2024]ZIP: 11KB

Thermal Simulation Model

Simplified CFD Model[Aug,2023]ZIP: 8KB

Reliability Information

Reliability Data[Dec,2024]PDF: 274KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Description

Application Scope Automotive / Switching Voltage Regulators / Motor Drivers / DC-DC Converters
Polarity N-ch
Generation U-MOSⅩ-H
Internal Connection Single
PPAP Capable(*)
AEC-Q101 Qualified(*)
RoHS Compatible Product(s) (#) Available

*: For detail information, please contact to our sales.

Package Information

Toshiba Package Name L-TOGL
Package Image L-TOGL
Pins 9
Mounting Surface Mount
Width×Length×Height
(mm)		 9.9×11.81×2.3
Package Dimensions 보기
Land pattern dimensions 보기

 Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Drain-Source voltage VDSS 100 V
Gate-Source voltage VGSS +/-20 V
Drain current ID 300 A
Power Dissipation PD 750 W

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Gate threshold voltage (Max) Vth - 3.5 V
Gate threshold voltage (Min) Vth - 2.5 V
Drain-Source on-resistance (Max) RDS(ON) |VGS|=6V 1.93 mΩ
Drain-Source on-resistance (Max) RDS(ON) |VGS|=10V 1.03 mΩ
Input capacitance (Typ.) Ciss - 16500 pF
Total gate charge (Typ.) Qg VGS=10V 269 nC
Reverse recovery time (Typ.) trr - 122 ns
Reverse recovery charge (Typ.) Qrr - 369 nC
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.

Document

  • If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Jun,2023

Jul,2023

Aug,2024

Aug,2024

Aug,2023

Dec,2024

(Note1)

LTspice ® is a trademark and simulation software of ADI (Analog Devices, Inc.).

(Note2)

SIMetrix® is simulation software and registered trademarks of SIMetrix Technologies Ltd.

(Note3)

ELDO™ is a trademark and simulation software of Siemens Industry Software Inc.
Click here for the list of trademarks related to Siemens Industry Software Inc.

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS AEC-Q100
AEC-Q101
XPQ1R00AQB,LQ 1500 Yes -
XPQ1R00AQB,LXHQ 1500 - Yes Yes

애플리케이션

Automotive DC-DC Converter
Such as reduction of power consumption and miniaturization are important in designing DC-DC converter. Toshiba provides information on a wide range of semiconductor products suitable for step-up or step-down DC-DC converter units, etc., along with circuit configuration examples.
세부 사항
Automotive Engine Control
Such as reduction of power consumption and miniaturization are important in designing engine control. Toshiba provides information on a wide range of semiconductor products suitable for power management circuit, injector drive circuit, actuator drive circuit, etc., along with circuit configuration examples.
세부 사항
Automotive Electric Turbocharger
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in designing electric turbocharger. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, communication units, etc., along with circuit configuration examples.
세부 사항
Automotive HVAC
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in designing HVAC. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, etc., along with circuit configuration examples.
세부 사항
Automotive Integrated Starter Generator
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in designing ISG. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, communication units, power supply units, etc., along with circuit configuration examples.
세부 사항
Automotive LED Headlamp
Such as reduction of power consumption and miniaturization of circuit boards are important in designing LED headlamp. Toshiba provides information on a wide range of semiconductor products suitable for LED matrix control units, power supply units, etc., along with circuit configuration examples.
세부 사항
Automotive On-board Charger
Such as reduction of power consumption and miniaturization of circuit boards are important in designing on-board charger. Toshiba provides information on a wide range of semiconductor products suitable for DC-DC converter units, power supply units, etc., along with circuit configuration examples.
세부 사항
