Feature	2.3mm low-profile package / DC input
Application Scope	Communication interface / PLC / Power supply
Function	General-purpose
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

Package Information

Toshiba Package Name	4pin SO6
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.7×7.0×2.1
Package Dimensions	보기
Land pattern dimensions	보기
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note)

Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Collector-emitter voltage	V_CEO	80	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.05	A
Operating Temperature	T_opr	-55 to 110	℃

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.3	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	3750	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=-	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=-	50	%

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

Data sheet TLP185(SE Data sheet/Japanese

PDF: 440KB

Nov,2019

Data sheet TLP185(SE Data sheet/English

PDF: 291KB

Nov,2019

Simulation Model PSpice Model ZIP

ZIP: 4KB

Oct,2018

Simulation Model LTspice Model (Note) ZIP

ZIP: 7KB

Feb,2019

Reliability Information Reliability Data

PDF: 203KB

Dec,2023

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 86KB

Dec,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 86KB

Dec,2024

Application Note Safety standards for photocouplers

PDF: 753KB

Mar,2021

Application Note Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Application Note Application note for phototransistor coupler

PDF: 846KB

Feb,2018

Catalog Selection Guide Isolators and Solid State Relays 2024Rev2.0

PDF: 14710KB

Aug,2024

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

(Note)

LTspice ^® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Orderable part number

Orderable part number (example)	MOQ(pcs)	RoHS	Current Transfer Ratio (%)	VDE
TLP185(BL-TPL,SE	3000	Yes	BL (200%-600%)	-
TLP185(BLL-TL,SE	3000	Yes	BLL(200%-400%)	-
TLP185(GB-TPL,SE	3000	Yes	GB(100%-600%)	-
TLP185(GR-TPL,SE	3000	Yes	GR(100%-300%)	-
TLP185(GRH-TL,SE	3000	Yes	GRH(150%-300%)	-
TLP185(GRL-TL,SE	3000	Yes	GRL(100%-200%)	-
TLP185(TPL,SE	3000	Yes	-	-
TLP185(V4-TPL,SE	3000	Yes	-	Yes
TLP185(V4B-TL,SE	3000	Yes	BLL(200%-400%)	Yes
TLP185(V4BLTL,SE	3000	Yes	BL (200%-600%)	Yes
TLP185(V4GBTL,SE	3000	Yes	GB(100%-600%)	Yes
TLP185(V4GHTL,SE	3000	Yes	GRH(150%-300%)	Yes
TLP185(V4GLTL,SE	3000	Yes	GRL(100%-200%)	Yes
TLP185(V4GRTL,SE	3000	Yes	GR(100%-300%)	Yes
TLP185(V4Y-TL,SE	3000	Yes	Y(50%-150%)	Yes
TLP185(V4YHTL,SE	3000	Yes	YH(75%-150%)	Yes
TLP185(Y-TPL,SE	3000	Yes	Y(50%-150%)	-
TLP185(YH-TPL,SE	3000	Yes	YH(75%-150%)	-

애플리케이션

IH Rice Cooker

Such as high breakdown voltage, low power consumption and miniaturization are important in designing IH rice cooker. Toshiba provides information on a wide range of semiconductor products suitable for IH coil driving units, motor driving units, heater control unit, etc., along with circuit configuration examples.

세부 사항

IH Cooking Heater

Such as high breakdown voltage, low power consumption and miniaturization are important in designing IH cooking heater. Toshiba provides information on a wide range of semiconductor products suitable for IH coil driving units, motor driving units, current detecting unit, etc., along with circuit configuration examples.

세부 사항

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
