TW060N120C

Power SiC MOSFETs

Data sheet

TW060N120C Data sheet/Japanese[Sep,2024]PDF: 630KB

Data sheet

TW060N120C Data sheet/English[Sep,2024]PDF: 520KB

Simulation Model

PSpice Model[May,2023]ZIP: 44KB

Simulation Model

LTspice Model[Apr,2023]ZIP: 50KB

Simulation Model

SIMetrix Model[Apr,2023]ZIP: 10KB

Simulation Model

PLECS Model[Nov,2024]ZIP: 6KB

Thermal Simulation Model

Simplified CFD Model[Oct,2023]ZIP: 10KB

Reliability Information

Reliability Data[Oct,2024]PDF: 174KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 86KB

Application Note

Features of third generation SiC MOSFET[Jun,2023]PDF: 1316KB

Application Note

MOSFET SPICE model grade[May,2023]PDF: 1639KB

Application Note

FAQ: SiC MOSFET Application Notes[Mar,2021]PDF: 801KB

Application Note

Comparison of SiC MOSFET and Si IGBT: SiCMOSFET Application Notes[Aug,2020]PDF: 907KB

Application Note

Absolute Maximum Ratings and Electrical Characteristics: SiCMOSFET Application Notes[Aug,2020]PDF: 792KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Data sheet

TW060N120C Data sheet/Japanese[Sep,2024]PDF: 630KB

Data sheet

TW060N120C Data sheet/English[Sep,2024]PDF: 520KB

Application Note

Features of third generation SiC MOSFET[Jun,2023]PDF: 1316KB

Application Note

MOSFET SPICE model grade[May,2023]PDF: 1639KB

Application Note

FAQ: SiC MOSFET Application Notes[Mar,2021]PDF: 801KB

Application Note

Comparison of SiC MOSFET and Si IGBT: SiCMOSFET Application Notes[Aug,2020]PDF: 907KB

Application Note

Absolute Maximum Ratings and Electrical Characteristics: SiCMOSFET Application Notes[Aug,2020]PDF: 792KB

Simulation Model

PSpice Model[May,2023]ZIP: 44KB

Simulation Model

LTspice Model[Apr,2023]ZIP: 50KB

Simulation Model

SIMetrix Model[Apr,2023]ZIP: 10KB

Simulation Model

PLECS Model[Nov,2024]ZIP: 6KB

Thermal Simulation Model

Simplified CFD Model[Oct,2023]ZIP: 10KB

Reliability Information

Reliability Data[Oct,2024]PDF: 174KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 86KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Description

Application Scope Switching regulators
Polarity N-ch
RoHS Compatible Product(s) (#) Available

Package Information

Toshiba Package Name TO-247
Package Image TO-247
Pins 3
Mounting Through Hole
Width×Length×Height
(mm)		 15.94×20.95×5.02
Package Dimensions 보기

 Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Drain-Source voltage VDSS 1200 V
Gate-Source voltage VGSS +25/-10 V
Drain current ID 36 A
Power Dissipation PD 170 W

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Gate threshold voltage (Max) Vth - 5.0 V
Gate threshold voltage (Min) Vth - 3.0 V
Drain-Source on-resistance (Typ.) RDS(ON) |VGS|=18V 60 mΩ
Input capacitance (Typ.) Ciss - 1530 pF
Total gate charge (Typ.) Qg - 46 nC
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.
