This reference design provides design guide, data and other contents of 100 W LLC DC-DC Converter which uses Zero Volt Switching implemented using LLC resonance.
Click on components for more details
|Input voltage||DC 22.8 to 25.2 V|
|Output voltage||DC 12 V|
|Output power||100 W|
|Circuit topology||LLC Resonance + Synchronous Rectification Circuit|
Design Documents contain the documents below.
Design Data contains the contents listed below.
|Part Number||Device Category||Portion Usage||Description|
|Power MOSFET (N-ch single 30V<VDSS≤60V)||Primary-side main switch・2||N-ch MOSFET, 40 V, 0.0075 Ω@10V, TSON Advance, U-MOSⅨ-H|
|Power MOSFET (N-ch single 30V<VDSS≤60V)||Secondary-side・2||N-ch MOSFET, 40 V, 0.00124 Ω@10V, SOP Advance, U-MOSⅨ-H|
