SSM3K347R

Small Low ON resistance MOSFETs

Data sheet

SSM3K347R Data sheet/Japanese[Sep,2016]PDF: 375KB

Data sheet

SSM3K347R Data sheet/English[Sep,2016]PDF: 277KB

Simulation Model

PSpice Model[Dec,2016]lib: 3KB

Simulation Model

LTspice Model[Feb,2019]mod: 21KB

Thermal Simulation Model

Simplified CFD Model[Feb,2024]ZIP: 8KB

Reliability Information

Reliability Data[Nov,2024]PDF: 276KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 86KB

Application Note

Surface Mount Small Signal MOSFET Precautions for use[Jan,2022]PDF: 830KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Data sheet

SSM3K347R Data sheet/Japanese[Sep,2016]PDF: 375KB

Data sheet

SSM3K347R Data sheet/English[Sep,2016]PDF: 277KB

Application Note

Surface Mount Small Signal MOSFET Precautions for use[Jan,2022]PDF: 830KB

Simulation Model

PSpice Model[Dec,2016]lib: 3KB

Simulation Model

LTspice Model[Feb,2019]mod: 21KB

Thermal Simulation Model

Simplified CFD Model[Feb,2024]ZIP: 8KB

Reliability Information

Reliability Data[Nov,2024]PDF: 276KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 86KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Description

Application Scope Relay Drivers
Feature Active clamp
Polarity N-ch + Active Clamp Zener
Generation U-MOSⅣ
Internal Connection Single
AEC-Q101 Qualified(*)
RoHS Compatible Product(s) (#) Available

*: For detail information, please contact to our sales.

Package Information

Toshiba Package Name SOT-23F
Package Image SOT-23F
Pins 3
Mounting Surface Mount
Width×Length×Height
(mm)		 2.9×2.4×0.8
Package Dimensions 보기
Land pattern dimensions 보기
CAD data
(Symbol, Footprint and 3D model)		 Download from UltraLibrarian<sup>®</sup> in your desired CAD format (Note)

Download from UltraLibrarian® in your desired CAD format (Note)

 Please refer to the link destination to check the detailed size.

(Note)

Ultra Librarian® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Drain-Source voltage VDSS 38 V
Gate-Source voltage VGSS +/-20 V
Drain current ID 2.0 A
Power Dissipation PD 1.0 W

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Gate threshold voltage (Max) Vth - 2.4 V
Gate threshold voltage (Min) Vth - 1.4 V
Drain-Source on-resistance (Max) RDS(ON) |VGS|=4V 480 mΩ
Drain-Source on-resistance (Max) RDS(ON) |VGS|=4.5V 410 mΩ
Drain-Source on-resistance (Max) RDS(ON) |VGS|=10V 340 mΩ
Input capacitance (Typ.) Ciss - 86 pF
Total gate charge (Typ.) Qg VGS=10V 2.5 nC
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.

Document

  • If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Dec,2016

Feb,2019

Feb,2024

Nov,2024

Dec,2024

Dec,2024

(Note)

LTspice ® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS AEC-Q100
AEC-Q101		 Note
SSM3K347R,LF 3000 Yes - General Use
SSM3K347R,LXGF 3000 - Yes Yes (Note) Unintended Use (Note)

(Note)：For more information, please contact our sales or use the inquiry form on our website.
