TLP5222

Photocoupler (photo-IC output)

  • Related Reference Design(1)

Data sheet

TLP5222 Data sheet/Japanese[Jul,2022]PDF: 3406KB

Data sheet

TLP5222 Data sheet/English[Jul,2022]PDF: 2965KB

Simulation Model

PSpice Model[Dec,2023]ZIP: 19KB

Reliability Information

Reliability Data[Dec,2023]PDF: 175KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 84KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 84KB

Application Note

Smart Gate Driver Coupler Tips for Designing DESAT Detection Circuits[May,2022]PDF: 1055KB

Application Note

Smart Gate Driver TLP5214A/TLP5214/TLP5212/TLP5222 Application Note -Introduction-[Apr,2022]PDF: 1534KB

Application Note

Smart Gate Driver Coupler TLP5214/TLP5214A/TLP5212/TLP5222 Appication Note -Advanced edition-[Apr,2022]PDF: 2189KB

Application Note

Safety standards for photocouplers[Mar,2021]PDF: 753KB

Application Note

Glossary of Photocoupler and Photorelay Terms[Mar,2018]PDF: 509KB

Catalog

Selection Guide Isolators and Solid State Relays 2024Rev2.0[Aug,2024]PDF: 14710KB

Catalog

Photocouplers and Photorelays[Apr,2020]PDF: 2619KB

Data sheet

TLP5222 Data sheet/Japanese[Jul,2022]PDF: 3406KB

Data sheet

TLP5222 Data sheet/English[Jul,2022]PDF: 2965KB

Application Note

Smart Gate Driver Coupler Tips for Designing DESAT Detection Circuits[May,2022]PDF: 1055KB

Application Note

Smart Gate Driver TLP5214A/TLP5214/TLP5212/TLP5222 Application Note -Introduction-[Apr,2022]PDF: 1534KB

Application Note

Smart Gate Driver Coupler TLP5214/TLP5214A/TLP5212/TLP5222 Appication Note -Advanced edition-[Apr,2022]PDF: 2189KB

Application Note

Safety standards for photocouplers[Mar,2021]PDF: 753KB

Application Note

Glossary of Photocoupler and Photorelay Terms[Mar,2018]PDF: 509KB

Simulation Model

PSpice Model[Dec,2023]ZIP: 19KB

Reliability Information

Reliability Data[Dec,2023]PDF: 175KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 84KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 84KB

Catalog

Selection Guide Isolators and Solid State Relays 2024Rev2.0[Aug,2024]PDF: 14710KB

Catalog

Photocouplers and Photorelays[Apr,2020]PDF: 2619KB

Description

Feature 2.5A peak current / Power device desaturation detection / Power device soft gate turn-off / Isolated fault status feedback
Application Scope Factory automation / Inverter / PV inverter
Function IGBT driver
Number of Circuits 1
Output Interface totem-pole(BUF)
RoHS Compatible Product(s) (#) Available
Safety Standard Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC)

*Download Online Certification of Safety Standard(UL 1577)
*Download Online Certification of Safety Standard(cUL)

Package Information

Toshiba Package Name SO16L
Package Image SO16L
Pins 16
Mounting Surface Mount
Width×Length×Height
(mm)		 10.3×10.0×2.1
Package Dimensions 보기
Land pattern dimensions 보기

 Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics Symbol Rating Unit
Supply Voltage VCC2-VEE -0.5 to 35 V
Operating Temperature Topr -40 to 110 ℃

Electrical Characteristics

Characteristics Symbol Condition Value Unit
Pulse width distortion |tpHL-tpLH| - 50 ns
Isolation voltage BVS t=60sec 5000 Vrms
Common mode transient immunity CMH / CML - +/-25 kV/μs
ICC2 (Max) ICC2 - 5 mA
threshold input current(L/H) IFLH - 6 mA
Output Current Iout (peak) (Max) IOP - +/-2.5 A
Propagation delay time (H/L)(Max) tpHL - 250 ns
Propagation delay time (H/L)(Typ.) tpHL - 165 ns
Propagation delay time (L/H)(Max) tpLH - 250 ns
Propagation delay time (L/H)(Typ.) tpLH - 170 ns
Supply Voltage(under Recommended Operating Conditions)(Max) VCC2-VE - 30 V
Supply Voltage(under Recommended Operating Conditions)(Min) VCC2-VE - 15 V
Purchase and Sample
Please contact one of Toshiba's official distributors or the nearest Toshiba sales office.
You can search for and purchase a small on-line sample by clicking on the following link.

Document

  • If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Dec,2023

Dec,2023

Dec,2024

Dec,2024

Reference Design

This is a picture of Isolated Gate Drive Circuit for 3-Phase Inverter.
Isolated Gate Drive Circuit for 3-Phase Inverter
In recent years, 3-phase inverters in industrial equipment have become important to achieving a low-carbon society. This is the gate drive circuit with various protection functions which can safely drive the power module used for the 3-phase inverter.
Design tips on each portion of the circuit, method of operation, and design information such as circuit diagrams and PCB patterns are available, please use them for your design.
세부 사항

애플리케이션

Inverter/Servo
Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.
세부 사항
Uninterruptible power supply
Such as low power consumption and miniaturization are important in designing uninterruptible power supply (UPS). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, inverter/converter units, control units, signal transmission units, etc., along with circuit configuration examples.
세부 사항
