TC78H660FNG

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

Site Map

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Function	4 function modes (CW / CCW / STOP / Short BRAKE) / Capable of constant current controlling (PWM) / Standby function
Application Scope	DC motor drivers / Stepping motor drivers
Class	DC and stepping motor driver IC
Number of drive motors (brush moter)	2
Number of drive motors (stepping motor)	1
RoHS Compatible Product(s) (#)	Available

Toshiba Package Name	P-TSSOP16-0505-0.65-001
Pins	16
Mounting	Surface Mount

Characteristics	Symbol	Rating	Unit
Output Current	I_OUT(peak)	2.0	A
Operating Temperature (Max)	T_opr	85	℃
Operating Temperature (Min)	T_opr	-40	℃
Supply Voltage	V_CC	18	V
Output Voltage	V_O	18	V
