Intelligent Power ICs

Toshiba's extensive lineup of intelligent power ICs ranges from 40V and 60V low-voltage power ICs to 250V and 600V high-voltage power ICs.
The low-voltage power ICs have protection functions for overcurrent, thermal shutdown, etc., and diagnostic output. They are mainly used in automotive and amusement applications.
The high-voltage power ICs also have protection functions for overcurrent, thermal shutdown, etc. They are applied in brushless DC motors of home appliances.

Lineup

3-phase Brushless DC Motor Driver ICs, built-in Power Devices
Toshiba offers squarewave- and sinewave-control product lineups, covering 250V to 600V rated voltage and 0.7A to 5A rated current, that are suitable for home-appliance motors and industrial motors.
Automotive driver ICs
Toshiba has high/low side switch , gate driver and etc. which contained the protection functions and the diagnostic function for automotive application.
Consumer driver ICs
Toshiba offers high-/low-side switches, gate drivers, etc. that include the protection and diagnostic functions necessary for amusement or industrial motor applications.

Cross Reference Search

About information presented in this cross reference

The information presented in this cross reference is based on TOSHIBA's selection criteria and should be treated as a suggestion only. Please carefully review the latest versions of all relevant information on the TOSHIBA products, including without limitation data sheets and validate all operating parameters of the TOSHIBA products to ensure that the suggested TOSHIBA products are truly compatible with your design and application.
Please note that this cross reference is based on TOSHIBA's estimate of compatibility with other manufacturers' products, based on other manufacturers' published data, at the time the data was collected.
TOSHIBA is not responsible for any incorrect or incomplete information. Information is subject to change at any time without notice.

Documents

Technical topics

Reference Design

3-phase bridge drive circuit for automotive and industrial BLDC motors
Introduction of application to 3-phase brushless motor drive circuit combining TPD7212F/FN and TPD7104AF and power MOSFET

Design / Support / Reference Design Center

TPD4162F Square-Wave Control Type BLDC Motor Drive Circuit
The squea-wave controll type brushless DC motor driver using TPD4162F in compact pakage. The design method of circuit and PCB such as calculation of constanat, is described.

Small package / Power loss 10% down / Fast OCP operation

Single-Output High-Side N-Channel Power MOSFET Gate Driver Application and Circuit of the TPD7104AF
This reference design provides examples of application circuit and simulation for TPD7104AF which features short load protection, reverse power connection protection and others.

Semiconductor / power supply / power management / topology / flyback / AC-DC / MOSFET / diode
