This reference design provides design guide, data and other contents of 1 kW server power supply using phase shifetd full-bridge DC-DC converter.
Click on components for more details
Materials for designers, such as an overview of circuit operation and explanations of design considerations. Please click on each tab to view the contents.
Provides circuit data that can be loaded into EDA tools, PCB layout data, and data used in PCB manufacturing. Available in formats from multiple tool vendors. You can freely edit it with your preferred tool.
|Part Number||Device Category||Portion Usage||Description|
|Power MOSFET (N-ch single 60V<VDSS≤150V)||Primary-side・4||N-ch MOSFET, 80 V, 0.00243 Ω@10V, SOP Advance, U-MOSⅩ-H|
|Power MOSFET (N-ch single 60V<VDSS≤150V)||Secondary-side・8||N-ch MOSFET, 150 V, 0.0154 Ω@10V, SOP Advance, U-MOSⅧ-H|
|Photocoupler (photo-IC output)||Communication between primary-side and secondary-side ・2||Photocoupler (photo-IC output), High-speed, 20 Mbps, 3750 Vrms, 5pin SO6|
|Photocoupler (phototransistor output)||Output voltage feedback・1||Photocoupler (phototransistor output), DC input, 3750 Vrms, SO4|
We provide materials useful for designing and considering similar circuits, such as application notes for installed products. Please click on each tab to view the contents.
