One-Gate Logic ICs (L-MOS)
Toshiba started to release one-gate logic (L-MOS) for the first time in the industry in the latter half of the 1980s.
L-MOS contains a small number of logic circuits (1 to 3) and is available in various packages with a small number of pins (5 to 8 pins) from industry standard general-purpose packages to ultra-small packages. L-MOS provides flexibility against logic mistakes in circuit design, and contributes to the miniaturization of designs in a multitude of applications.
Toshiba offer a wide range of L-MOS products, from the standard TC4S / 4W series which guarantees operation at high power supply voltages (~ 18V), to the high-speed 7UL series which guarantees operation at 0.9V.
Lineup
You can narrow down the search for applicable products by selecting specifications.
You can narrow down your search for applicable products by package type or number of pins.
- SOT-953 (fSV)
-
Package Size
W : 1.0 mm 0.039 inch L : 1.0 mm 0.039 inch H : 0.48 mm 0.019 inch
- SOT-553 (ESV)
-
Package Size
W : 1.6 mm 0.063 inch L : 1.6 mm 0.063 inch H : 0.55 mm 0.022 inch
- SOT-353 (USV)
-
Package Size
W : 2.0 mm 0.079 inch L : 2.1 mm 0.083 inch H : 0.9 mm 0.035 inch
- SOT-25 (SMV)
-
Package Size
W : 2.9 mm 0.11 inch L : 2.8 mm 0.11 inch H : 1.1 mm 0.043 inch
.png)
- XSON6(MP6D)
-
Package Size
W : 1.45 mm 0.057 inch L : 1.0 mm 0.039 inch H : 0.48 mm 0.019 inch
- SOT-363 (US6)
-
Package Size
W : 2.0 mm 0.079 inch L : 2.1 mm 0.083 inch H : 0.9 mm 0.035 inch
- SOT-765 (US8)
-
Package Size
W : 2.0 mm 0.079 inch L : 3.1 mm 0.12 inch H : 0.7 mm 0.028 inch
- SOT-505 (SM8)
-
Package Size
W : 2.9 mm 0.11 inch L : 4.0 mm 0.16 inch H : 1.1 mm 0.043 inch
All package dimensions are guaranteed in millimeters as mentioned on datasheet. Package dimension in inches is round to 2 significant digits converted with 1mm=0.0393701inch.
require 3 characters or more.
About information presented in this cross reference
The information presented in this cross reference is based on TOSHIBA's selection criteria and should be treated as a suggestion only. Please carefully review the latest versions of all relevant information on the TOSHIBA products, including without limitation data sheets and validate all operating parameters of the TOSHIBA products to ensure that the suggested TOSHIBA products are truly compatible with your design and application.
Please note that this cross reference is based on TOSHIBA's estimate of compatibility with other manufacturers' products, based on other manufacturers' published data, at the time the data was collected.
TOSHIBA is not responsible for any incorrect or incomplete information. Information is subject to change at any time without notice.
