Description

Application Scope	High-Speed Switching
Polarity	N-ch
Generation	U-MOSⅦ-H
Internal Connection	Single
PPAP	Capable(*)
AEC-Q101	Qualified(*)
RoHS Compatible Product(s) (#)	Available

*: For detail information, please contact to our sales.

Package Information

Toshiba Package Name	SOT-346 (S-Mini)
Package Image
JEITA	SC-59
JEDEC	TO-236MOD
Package Code	SOT-346
Pins	3
Mounting	Surface Mount
Width×Length×Height (mm)	2.9×2.5×1.1
Package Dimensions	View
Land pattern dimensions	View
Ultra Librarian^® CAD model (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note1)(Note3)
SamacSys CAD model (Symbol, Footprint and 3D model)	Download from SamacSys (Note2)(Note3)

Please refer to the link destination to check the detailed size.

(Note1)	Ultra Librarian^® is a Registered trademark and CAD model library of EMA (EMA Design Automation, Inc.). CAD models (Symbol/Footprint /3D model) are provided by UltraLibrarian^®. The footprints are generated based on the specifications of Ultra Librarian^®.
(Note2)	SamacSys is a wholly owned subsidiary of Supplyframe, Inc. CAD models (Symbol/Footprint /3D model) are provided by Supplyframe, Inc. The footprints are generated based on the specifications of SamacSys.
(Note3)	Please note that the footprint dimensions may differ from the reference Land Pattern dimensions provided on our website.

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Drain-Source voltage	V_DSS	60	V
Gate-Source voltage	V_GSS	+/-20	V
Drain current	I_D	400	mA
Power Dissipation	P_D	0.27	W

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Gate threshold voltage (Max)	V_th	-	2.1	V
Gate threshold voltage (Min)	V_th	-	1.1	V
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=4.5V	1.75	Ω
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=5V	1.65	Ω
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=10V	1.5	Ω
Input capacitance (Typ.)	C_iss	-	26	pF
Total gate charge (Typ.)	Q_g	V_GS=4.5V	0.39	nC

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

Data sheet SSM3K7002KF Data sheet/Japanese

PDF: 342KB

May,2021

Data sheet SSM3K7002KF Data sheet/English

PDF: 227KB

May,2021

Simulation Model PSpice Model lib

lib: 3KB

Sep,2016

Simulation Model LTspice Model (Note) mod

mod: 20KB

Feb,2019

Reliability Information Reliability Data

PDF: 273KB

Feb,2025

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 86KB

Apr,2025

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 86KB

Apr,2025

Application Note Surface Mount Small Signal MOSFET Precautions for use

PDF: 830KB

Jan,2022

Catalog Selection Guide MOSFETs 2025 Rev1.0

PDF: 3497KB

Feb,2025

Catalog Selection Guide Small Signal 2025 Rev1.0

PDF: 8498KB

Feb,2025

Catalog Mini catalog Introduction of Semi-power & small-size low RON MOSFET

PDF: 433KB

Dec,2024

Catalog Mini catalog Introduction of small-package MOSFET

PDF: 680KB

Dec,2024

(Note)

LTspice ^® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Orderable part number

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	AEC_Q100-Q101	Note
SSM3K7002KF,LF	3000		Yes	-	General Use
SSM3K7002KF,LXGF	3000	-	Yes	Yes (Note)	Unintended Use (Note)
SSM3K7002KF,LXHF	3000	-	Yes	Yes	Automotive Use

(Note)：For more information, please contact our sales or use the inquiry form on our website.
