TPD4163F

This page partially uses JavaScript. This page may not operate normally when these functions are not supported by your browser or the setting is disabled.
Please look for the information you need from the following pages:

Site Map

Asia-Pacific - English

Asia-Pacific - 简体中文

Asia-Pacific - 繁體中文

Asia-Pacific - 한국어

Asia-Pacific - 日本語

Americas - English

Europe (EMEA) - English

Feature	5V Voltage Regulator
Number of Circuits	1
Protection Functions	Overcurrent / Thermal shutdown / Overvoltage
Output configuration	3-phase full-bridge
Drive Type	Sine-wave / Square-wave
Control Circuit	Non-built-in
Power Block	IGBT
RoHS Compatible Product(s) (#)	Available

Package Information

Toshiba Package Name	HSSOP31
Package Image
Pins	31
Mounting	Surface Mount
Width×Length×Height (mm)	17.5×11.93×2.2
Package Dimensions	View

Please refer to the link destination to check the detailed size.

Absolute Maximum Ratings

Characteristics	Symbol	Rating	Unit
Output current(DC)	I_OUT(DC)	1	A
Power Supply Voltage	V_BB	600	V
Power Supply Voltage	V_CC	20	V

Electrical Characteristics

Characteristics	Symbol	Condition	Value	Unit
Operating power supply voltage	V_BB	-	50 to 450	V
Operating power supply voltage	V_CC	-	13.5 to 16.5	V
Output saturation voltage (Max)	V_CEsatH	-	3.3	V
Output saturation voltage (Max)	V_CEsatL	-	3.3	V

Document

select all
If the checkbox is invisible, the corresponding document cannot be downloaded in batch.

Name
Date

UPDATED Data sheet TPD4163F Data sheet/Japanese

PDF: 690KB

Oct,2024

UPDATED Data sheet TPD4163F Data sheet/English

PDF: 513KB

Oct,2024

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 85KB

Nov,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 85KB

Nov,2024

Application Note TPD4163_TPD4164_TPD4165 Application Note

PDF: 1288KB

Aug,2023

Application Note Simplified CFD Model Application Note

PDF: 993KB

Nov,2022

Application Note DC-AC Inverter Circuit

PDF: 1946KB

Jul,2018

Application Note Glossary of High-Voltage Intelligent Power Device Terms

PDF: 601KB

Apr,2018

Catalog Selection Guide Power Devices 2024 Rev2.0

PDF: 10449KB

Aug,2024

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS
TPD4163F,LF	1000	-	Yes

Applications

Air Conditioner

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing air conditioner. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

Details

Air Cleaner

Such as high efficiency, low power consumption and miniaturization are important in designing air cleaner. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving units, sensor signal input unit, etc., along with circuit configuration examples.

Details

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.

Automotive Category Top View

Body Electronics

xEV

In-Vehicle Infotainment

Advanced Driver-Assistance Systems (ADAS)

Chassis

Industrial Equipment Category Top View

Infrastructure

BEMS/HEMS

Factory Automation

Commercial Equipment

Consumer / Personal Equipment Category Top View

IoT Equipment

Healthcare

Wearable Device

Mobile

Computer Peripherals

Home Applicances

Others

Description

Package Information

Absolute Maximum Ratings

Electrical Characteristics

Document

Orderable part number

Applications

Technical inquiry

Related Links

Notes
