Linear Image Sensors

1. TCD: Toshiba CCD Linear Image Sensor

2. About color filter

• 1: Black and White Only
• 2: Color or Black and White + Color

3. Pixel counts (per line)

• 1: 1000 to 1999
• 2: 2000 to 2999
• 3: 3000 to 3999
• 4: 4000 to 4999
• 5: 5000 to 5999
• 6: 6000 to 6999
• 7: 7000 to 7999
• 8: 8000 to 8999
• 9: 9000 to 9999

4. Product peculiar name: expressed with numbers

5. Package Materials and Shape

• D: DIP (CERDIP: CERamic Dual In-line Package)
• BF: QFN (CLCC: Ceramic Leadless Chip Carrier)
• GF: QFN (GLCC: Glass epoxy Leadless Chip Carrier)

6. G: lead-free package

7. Characteristics (to be added as needed)

• 1 to 2 digits
