Multi Function Printer

總方塊圖

Multi Function Printer

點選總方塊圖中要查看詳細資訊的區域。顯示我們建議的子方塊圖的連結。

Power supply circuit

Example of AC-DC converter circuit (flyback type)

Display block

Example of load switch circuit for ON/OFF control of LCD backlight

Scanner block

Example of load switch circuit for ON/OFF control of scanner light source

USB circuit

USB 2.0 circuit

Example of ESD protection circuit for USB signal line

ADF block FAX modem block

Examples of auto document feeder (ADF) and FAX modem circuits

Engine block/Heater block/Finisher block

Example of engine, heater and finisher block circuit

子方塊圖

Power supply circuit

Example of AC-DC converter circuit (flyback type)

Schottky barrier diode
Fast recovery diode
DTMOS Series MOSFET
Transistor output photocoupler
Bipolar transistor

Schottky barrier diode

器件型號	CMS15	CUHS20F60
Toshiba Package Name	M-FLAT	SOD-323HE (US2H)
V_RRM (Max) [V]	60
V_R (Max) [V]		60
C_T (Typ.) [pF]		300

搜尋產品線

Fast recovery diode

器件型號	CRF03A
Toshiba Package Name	S-FLAT
V_RRM (Max) [V]	600
I_F(AV) (Max) [A]	0.7

搜尋產品線

DTMOS Series MOSFET

器件型號	TK090E65Z	TK090U65Z	TK090A65Z	TK090N65Z
Toshiba Package Name	TO-220	TOLL	TO-220SIS	TO-247
V_DSS (Max) [V]	650	650	650	650
I_D (Max) [A]	30	30	30	30
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.09	0.09	0.09	0.09
Polarity	N-ch	N-ch	N-ch	N-ch

搜尋產品線

Transistor output photocoupler

器件型號	TLP383	TLP385	TLP387	TLP388
Toshiba Package Name	4pin SO6L	4pin SO6L	4pin SO6L	4pin SO6L
BV_S (Min) [V_rms] @ t = 60 [s]	5000	5000	5000	5000
V_CEO (Max) [V]	80	80	300	350
T_opr [°C]	-55 to 125	-55 to 110	-55 to 110	-55 to 125

搜尋產品線

Bipolar transistor

器件型號	TMBT3904
Toshiba Package Name	SOT-23 (SOT23)
V_CEO (Max) [V]	50
I_C (Max) [A]	0.2
Polarity	NPN

搜尋產品線

Display block

Example of load switch circuit for ON/OFF control of LCD backlight

Small signal MOSFET
TVS diode
MCU

Small signal MOSFET

器件型號	SSM3K35FS	SSM3K35AFS	SSM3J35FS	SSM3J35AFS
Toshiba Package Name	SOT-416 (SSM)	SOT-416 (SSM)	SOT-416 (SSM)	SOT-416 (SSM)
V_DSS (Max) [V]	20	20	-20	-20
I_D (Max) [A]	0.18	0.25	-0.1	-0.25
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 2.5 [V]	4.0	1.6	11	2.1
Polarity	N-ch	N-ch	P-ch	P-ch

搜尋產品線

TVS diode

器件型號	DF2B5M4ASL	DF2B6M4ASL	DF2B6USL	DF6D6UFE	DF2B6M4BSL
Toshiba Package Name	SOD-962 (SL2)	SOD-962 (SL2)	SOD-962 (SL2)	SOT-563 (ES6)	SOD-962 (SL2)
V_ESD (Max) [kV]	+/-16	+/-15	+/-10	+/-10	+/-8
I_R (Max) [µA]	0.1	0.1	0.1	0.1	0.1
R_dyn (Typ.) [Ω]	0.7	0.7	0.25	0.25	1.05
C_T (Typ.) [pF] @ V_R = 0 [V], f = 1 [MHz]	0.15	0.15	1.5	1.5	0.12

搜尋產品線

MCU (TX00 Series M060 Group)

Series	TX00 Series
Group	M060 Group

搜尋產品線

Scanner block

Example of load switch circuit for ON/OFF control of scanner light source

Small signal MOSFET
MCU
Stepping motor driver built-in AGC
Linear image sensor (CCD)

Small signal MOSFET

器件型號	SSM3K35FS	SSM3K35AFS	SSM3J35FS	SSM3J35AFS
Toshiba Package Name	SOT-416 (SSM)	SOT-416 (SSM)	SOT-416 (SSM)	SOT-416 (SSM)
V_DSS (Max) [V]	20	20	-20	-20
I_D (Max) [A]	0.18	0.25	-0.1	-0.25
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 2.5 [V]	4.0	1.6	11	2.1
Polarity	N-ch	N-ch	P-ch	P-ch

搜尋產品線

MCU (TXZ+^TM 4A Series M4G/M4N Group / TXZ+^TM 3A Series M3H Group / TX04 Series M460 Group)

Series	TXZ+^TM 4A Series	TXZ+^TM 4A Series	TXZ+^TM 3A Series	TX04 Series
Group	M4G Group	M4N Group	M3H Group	M460 Group

搜尋產品線

Stepping motor driver built-in AGC

器件型號	TB67S128FTG	TB67S289FTG
Toshiba Package Name	P-VQFN64-0909-0.50-006	P-VQFN48-0707-0.50-004
V_OUT (Max) [V]	50	50
I_OUT (Max) [A]	5	3
V_M [V]	6.5 to 44	10 to 47
R_ON (Typ.) [Ω]	0.25	0.4

搜尋產品線

Linear image sensor (CCD)

器件型號	TCD2569BFG	TCD2726DG
Toshiba Package Name	22pin CLCC	32pin CERDIP
Pixel Size [μm]	5.25×5.25
Pixel Size (Pitch) [μm]	5.25	4.7
Number of Pixels	5340×3 Line

搜尋產品線

USB circuit

USB 2.0 circuit

Example of ESD protection circuit for USB signal line

TVS diode

TVS diode

器件型號	DF2B5M4ASL	DF2B6M4ASL	DF2B6USL	DF6D6UFE	DF2B6M4BSL
Toshiba Package Name	SOD-962 (SL2)	SOD-962 (SL2)	SOD-962 (SL2)	SOT-563 (ES6)	SOD-962 (SL2)
V_ESD (Max) [kV]	+/-16	+/-15	+/-10	+/-10	+/-8
I_R (Max) [µA]	0.1	0.1	0.1	0.1	0.1
R_dyn (Typ.) [Ω]	0.7	0.7	0.25	0.25	1.05
C_T (Typ.) [pF] @ V_R = 0 [V], f = 1 [MHz]	0.15	0.15	1.5	1.5	0.12

搜尋產品線

ADF block FAX modem block

Examples of auto document feeder (ADF) and FAX modem circuits

MCU
Stepping motor driver
MCU

MCU (TXZ+^TM 4A Series M4G/M4N Group / TXZ+^TM 3A Series M3H Group / TX04 Series M460 Group)

Series	TXZ+^TM 4A Series	TXZ+^TM 4A Series	TXZ+^TM 3A Series	TX04 Series
Group	M4G Group	M4N Group	M3H Group	M460 Group

搜尋產品線

Stepping motor driver

器件型號	TB67S511FTAG	TB67S512FTAG	TB67S521FTAG	TB67S522FTAG	TB67S539FTG	TB67S549FTG
Toshiba Package Name	P-WQFN36-0606-0.50-002	P-WQFN36-0606-0.50-002	P-WQFN36-0606-0.50-002	P-WQFN36-0606-0.50-002	P-VQFN32-0505-0.50-004	P-VQFN24-0404-0.50-004
V_OUT (Max) [V]	40	40	40	40	40	40
I_OUT (Max) [A]	2	2	2.8	2.8	2.0	1.5
V_M [V]	10 to 35	10 to 35	10 to 35	10 to 35	4.5 to 33	4.5 to 33
R_ON (Typ.) [Ω]	0.8	0.8	0.53	0.53	0.8	1.2

搜尋產品線

MCU (TX00 Series M030 Group)

Series	TX00 Series
Group	M030 Group

搜尋產品線

Engine block/Heater block/Finisher block

Example of engine, heater and finisher block circuit

MCU (TXZ+^TM 4A Series M4G/M4N Group / TXZ+^TM 3A Series M3H Group / TX04 Series M460 Group)

Series	TXZ+^TM 4A Series	TXZ+^TM 4A Series	TXZ+^TM 3A Series	TX04 Series
Group	M4G Group	M4N Group	M3H Group	M460 Group

搜尋產品線

Stepping motor driver

器件型號	TB67S511FTAG	TB67S512FTAG	TB67S521FTAG	TB67S522FTAG	TB67S539FTG	TB67S549FTG
Toshiba Package Name	P-WQFN36-0606-0.50-002	P-WQFN36-0606-0.50-002	P-WQFN36-0606-0.50-002	P-WQFN36-0606-0.50-002	P-VQFN32-0505-0.50-004	P-VQFN24-0404-0.50-004
V_OUT (Max) [V]	40	40	40	40	40	40
I_OUT (Max) [A]	2	2	2.8	2.8	2.0	1.5
V_M [V]	10 to 35	10 to 35	10 to 35	10 to 35	4.5 to 33	4.5 to 33
R_ON (Typ.) [Ω]	0.8	0.8	0.53	0.53	0.8	1.2

搜尋產品線

MCU (TXZ+^TM 3A シリーズ M3H グループ)

Series	TXZ+^TM3A Series
Group	M3H Group

搜尋產品線

Three-phase brushless DC motor driver 　

器件型號	TC78B004AFTG
Toshiba Package Name	P-WQFN40-0606-0.50-001
V_OUT (Max) [V]	31
I_OUT (Max) [A]	0.1
V_M [V]	10 to 28
R_ON (Typ.) [Ω]

搜尋產品線

1ch brushed DC motor driver

器件型號	TB67H450AFNG	TB67H451AFNG
Toshiba Package Name	P-HSOP8-0405-1.27-002	P-HSOP8-0405-1.27-002
V_OUT (Max) [V]	50	50
I_OUT (Max) [A]	3.5	3.5
V_M [V]	4.5 to 44	4.5 to 44
R_ON(Normal) (Typ.) [Ω]	0.6	0.6
R_ON(Large) (Typ.) [Ω]

搜尋產品線

2ch brushed DC motor driver

器件型號	TB67H400AFTG	TB67H410FTG	TB67H420FTG
Toshiba Package Name	P-WQFN48-0707-0.50-003	P-WQFN48-0707-0.50-003	P-VQFN48-0707-0.50-004
V_OUT (Max) [V]	50	50	50
I_OUT (Max) [A]			4.5
V_M [V]	10 to 47	10 to 47	10 to 47
R_ON(Normal) (Typ.) [Ω]	0.49	0.8	0.33
R_ON(Large) (Typ.) [Ω]	0.245	0.4	0.165
