Programmable Logic Controller

總方塊圖

Programmable Logic Controller

點選總方塊圖中要查看詳細資訊的區域。顯示我們建議的子方塊圖的連結。

Digital input module circuit

Example of digital input module circuit by discrete solution

Digital output module circuit

Example of digital output module circuit by discrete solution

Power supply module circuit

Example of a power supply module circuit using a photocoupler for feedback

Analog input module circuit

Analog input module circuit (single channel)

Example of analog input module circuit by discrete solution

Analog output module circuit (multiple channels)

Example of analog output module circuit by discrete solution

MCU module circuit

MCU module (RS-485 communication) circuit

子方塊圖

Digital input module circuit

Example of digital input module circuit by discrete solution

TVS diode
Transistor output photocoupler (AC input)
IC output photocoupler for high speed communication (AC input)
IC output photocoupler for high speed communication (supports IEC 61131-2)
Standard digital isolator
One-gate logic IC

TVS diode

器件型號	DF2B7BSL	DF2B7AFS	DF2B7ACT	DF2B7AE	DF2B7AFU
Toshiba Package Name	SOD-962 (SL2)	SOD-923 (SOD-923)	SOD-882 (CST2)	SOD-523 (ESC)	SOD-323 (USC)
V_ESD (Max) [kV]	+/-30	+/-30	+/-30	+/-30	+/-30
I_R (Max) [µA]	0.1	0.1	0.1	0.1	0.1
R_dyn (Typ.) [Ω]	0.2	0.2	0.2	0.2	0.2
C_T (Typ.) [pF] @ V_R = 0 [V], f = 1 [MHz]	12	8.5	8.5	8.5	8.5

搜尋產品線

Transistor output photocoupler (AC input)

器件型號	TLP292	TLP292-4
Toshiba Package Name	SO4	SO16
BV_S (Min) [V_rms] @ t = 60 [s]	3750	3750
V_CEO (Max) [V]	80	80
T_opr [°C]	-55 to 125	-55 to 125

搜尋產品線

IC output photocoupler for high speed communication (AC input)

器件型號	TLP2395	TLP2398
Toshiba Package Name	5pin SO6	5pin SO6
BV_S (Min) [V_rms] @ t = 60 [s]	3750	3750
V_CC / V_DD (Min) [V]	3	3
V_CC / V_DD (Max) [V]	20	20
I_CC / I_DD (Max) [mA]	3	3
Output Interface	totem-pole(BUF)	totem-pole(INV)

搜尋產品線

IC output photocoupler for high speed communication (supports IEC 61131-2)

器件型號	TLP2363
Toshiba Package Name	5pin SO6
BV_S (Min) [V_rms] @ t = 60 [s]	3750
V_CC / V_DD (Min) [V]	2.7
V_CC / V_DD (Max) [V]	5.5
I_CC / I_DD (Max) [mA]	4
Output Interface	open-collector

搜尋產品線

Standard digital isolator

器件型號	DCL540C01	DCL540D01	DCL540L01	DCL540H01	DCL541A01	DCL541B01
Toshiba Package Name	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W
BV_S (Min) [V_rms] @ t = 60 [s]	5000	5000	5000	5000	5000	5000
V_DD (Min) [V]	2.25	2.25	2.25	2.25	2.25	2.25
V_DD (Max) [V]	5.5	5.5	5.5	5.5	5.5	5.5
Output Interface	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)

搜尋產品線

One-gate logic IC

器件型號	TC7WZ07FK	TC7WZ00FK
Toshiba Package Name	SOT-765 (US8)	SOT-765 (US8)
V_CC (Max) [V]	5.5	5.5
Function	Triple Non-Inverter (Open Drain)	Dual 2-Input NAND Gate

搜尋產品線

Digital output module circuit

Example of digital output module circuit by discrete solution

One-gate logic IC
Transistor output photocoupler (DC input)
IC output photocoupler for high speed communication (DC input)
Small signal MOSFET
Transistor array
Photorelay
Darlington transistor output photocoupler

One-gate logic IC

器件型號	TC7WZ07FK	TC7WZ00FK
Toshiba Package Name	SOT-765 (US8)	SOT-765 (US8)
V_CC (Max) [V]	5.5	5.5
Function	Triple Non-Inverter (Open Drain)	Dual 2-Input NAND Gate

搜尋產品線

Transistor output photocoupler (DC input)

器件型號	TLP293	TLP293-4
Toshiba Package Name	SO4	SO16
BV_S (Min) [V_rms] @ t = 60 [s]	3750	3750
V_CEO (Max) [V]	80	80
T_opr [°C]	-55 to 125	-55 to 125

搜尋產品線

IC output photocoupler for high speed communication (DC input)

器件型號	TLP2355	TLP2358
Toshiba Package Name	5pin SO6	5pin SO6
BV_S (Min) [V_rms] @ t = 60 [s]	3750	3750
V_CC / V_DD (Min) [V]	3	3
V_CC / V_DD (Max) [V]	20	20
I_CC / I_DD (Max) [mA]	3	3
Output Interface	totem-pole(BUF)	totem-pole(INV)

搜尋產品線

Small signal MOSFET

器件型號	SSM3K341R	SSM3K341TU
Toshiba Package Name	SOT-23F	SOT-323F (UFM)
V_DSS (Max) [V]	60	60
I_D (Max) [A]	6.0	6.0
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.036	0.036
Polarity	N-ch	N-ch

搜尋產品線

Transistor array

器件型號	TBD62003AFWG	TBD62083AFG	TBD62064AFG
Toshiba Package Name	SOL16	SOP18-P-375-1.27	HSOP16
Number of Circuits	7	8	4
I_OUT (Max) [mA/ch]	500	500	1500

搜尋產品線

Photorelay

器件型號	TLP241B	TLP3420
Toshiba Package Name	DIP4	VSON4
BV_S (Min) [V_rms] @ t = 60 [s]	5000	500
I_ON (Max) [A]	2.0	0.1
R_ON (Max) [Ω]	0.2	14
I_FT (Max) [mA]	3	3
I_FC (Max) [mA]

搜尋產品線

Darlington transistor output photocoupler

器件型號	TLP187	TLP627M
Toshiba Package Name	4pin SO6	DIP4
BV_S (Min) [V_rms] @ t = 60 [s]	3750	5000
V_CEO (Max) [V]	300	300
T_opr [°C]	-55 to 110	-55 to 110

搜尋產品線

Power supply module circuit

Example of a power supply module circuit using a photocoupler for feedback

π-MOSⅧ Series MOSFET
Transistor output photocoupler (DC input)

π-MOSⅧ Series MOSFET

器件型號	TK10A80E
Toshiba Package Name	TO-220SIS
V_DSS (Max) [V]	800
I_D (Max) [A]	10
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	1.0
Polarity	N-ch

搜尋產品線

Transistor output photocoupler (DC input)

器件型號	TLP383
Toshiba Package Name	4pin SO6L
BV_S (Min) [V_rms] @ t = 60 [s]	5000
V_CEO (Max) [V]	80
T_opr [°C]	-55 to 125

搜尋產品線

Analog input module circuit

Analog input module circuit (single channel)

Example of analog input module circuit by discrete solution

Standard digital isolator
High voltage CMOS linear regulator

Standard digital isolator

器件型號	DCL540C01	DCL540D01	DCL540L01	DCL540H01	DCL541A01	DCL541B01
Toshiba Package Name	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W
BV_S (Min) [V_rms] @ t = 60 [s]	5000	5000	5000	5000	5000	5000
V_DD (Min) [V]	2.25	2.25	2.25	2.25	2.25	2.25
V_DD (Max) [V]	5.5	5.5	5.5	5.5	5.5	5.5
Output Interface	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)

搜尋產品線

High voltage CMOS linear regulator

器件型號	TCR1HF18B	TCR1HF33B	TCR1HF50B
Toshiba Package Name	SOT-25 (SMV)	SOT-25 (SMV)	SOT-25 (SMV)
I_OUT (Max) [mA]	150	150	150
V_OUT [V]	1.8 to 5.0	1.8 to 5.0	1.8 to 5.0

搜尋產品線

Analog output module circuit (multiple channels)

Example of analog output module circuit by discrete solution

Standard digital isolator
High voltage CMOS linear regulator
Small surface mount LDO regulator

Standard digital isolator

器件型號	DCL540C01	DCL540D01	DCL540L01	DCL540H01	DCL541A01	DCL541B01
Toshiba Package Name	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W
BV_S (Min) [V_rms] @ t = 60 [s]	5000	5000	5000	5000	5000	5000
V_DD (Min) [V]	2.25	2.25	2.25	2.25	2.25	2.25
V_DD (Max) [V]	5.5	5.5	5.5	5.5	5.5	5.5
Output Interface	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)

搜尋產品線

High voltage CMOS linear regulator

器件型號	TCR1HF18B	TCR1HF33B	TCR1HF50B
Toshiba Package Name	SOT-25 (SMV)	SOT-25 (SMV)	SOT-25 (SMV)
I_OUT (Max) [mA]	150	150	150
V_OUT [V]	1.8 to 5.0	1.8 to 5.0	1.8 to 5.0

搜尋產品線

Small surface mount LDO regulator

器件型號	TCR3DF Series	TCR2EF Series
Toshiba Package Name	SOT-25 (SMV)	SOT-25 (SMV)
I_OUT (Max) [mA]	300	200
V_OUT [V]	1.0 to 4.5	1.0 to 5.0

搜尋產品線

MCU module circuit

MCU module (RS-485 communication) circuit

Standard digital isolator
High voltage CMOS linear regulator
Small surface mount LDO regulator
CMOS logic IC

Standard digital isolator

器件型號	DCL540C01	DCL540D01	DCL540L01	DCL540H01	DCL541A01	DCL541B01
Toshiba Package Name	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W	SOIC16-W
BV_S (Min) [V_rms] @ t = 60 [s]	5000	5000	5000	5000	5000	5000
V_DD (Min) [V]	2.25	2.25	2.25	2.25	2.25	2.25
V_DD (Max) [V]	5.5	5.5	5.5	5.5	5.5	5.5
Output Interface	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)	totem-pole(BUF)

搜尋產品線

High voltage CMOS linear regulator

器件型號	TCR1HF18B	TCR1HF33B	TCR1HF50B
Toshiba Package Name	SOT-25 (SMV)	SOT-25 (SMV)	SOT-25 (SMV)
I_OUT (Max) [mA]	150	150	150
V_OUT [V]	1.8 to 5.0	1.8 to 5.0	1.8 to 5.0

搜尋產品線

Small surface mount LDO regulator

器件型號	TCR3DF Series	TCR2EF Series
Toshiba Package Name	SOT-25 (SMV)	SOT-25 (SMV)
I_OUT (Max) [mA]	300	200
V_OUT [V]	1.0 to 4.5	1.0 to 5.0

搜尋產品線

CMOS logic IC

器件型號	74VHC125FT	74VHC541FT	74VHCV541FT
Toshiba Package Name	TSSOP14B	TSSOP20B	TSSOP20B
V_CC (Max) [V]	5.5	5.5	5.5
Function1	Buffer/Transceiver	Buffer/Transceiver	Buffer/Transceiver
Function2	Buffer	Buffer	Buffer

搜尋產品線
