Blood Glucose Meter

總方塊圖

Blood Glucose Meter

點選總方塊圖中要查看詳細資訊的區域。顯示我們建議的子方塊圖的連結。

ESD protection

Examples of protection circuits for signal lines such as switch buttons and displays

Control MCU power supply

Examples of power supply circuits for MCU and memory

Sensor circuit

Example of signal processing circuit for bioelectrical impedance measurement

子方塊圖

ESD protection

Examples of protection circuits for signal lines such as switch buttons and displays

TVS diode

TVS diode

器件型號	DF2B7ASL	DF2B5PCT	DF2B7PCT	DF2B7AFU
Toshiba Package Name	SOD-962 (SL2)	SOD-882 (CST2)	SOD-882 (CST2)	SOD-323 (USC)
V_ESD (Max) [kV]	+/-30	+/-30	+/-30	+/-30
I_R (Max) [µA]	0.1	0.1	0.1	0.1
R_dyn (Typ.) [Ω]	0.2	0.1	0.1	0.2
C_T (Typ.) [pF] @ V_R = 0 [V], f = 1 [MHz]	8.5	41	45	8.5

搜尋產品線

Control MCU power supply

Examples of power supply circuits for MCU and memory

Small surface mount LDO regulator(1)
Small surface mount LDO regulator(2)

Small surface mount LDO regulator(1)

器件型號	TCR15AG Series	TCR13AG Series	TCR8BM Series	TCR5BM Series
Toshiba Package Name	WCSP6F	WCSP6F	DFN5B	DFN5B
I_OUT (Max) [mA]	1500	1300	800	500
V_OUT [V]	0.6 to 3.6	0.55 to 3.6	0.8 to 3.6	0.8 to 3.6

搜尋產品線

Small surface mount LDO regulator(2)

器件型號	TCR5RG Series	TCR3RM Series	TCR3U Series	TCR2L Series	TAR5 Series
Toshiba Package Name	WCSP4F	DFN4F	WCSP4F	SOT-553 (ESV)	SOT-25 (SMV)
I_OUT (Max) [mA]	500	300	300	200	200
V_OUT [V]	0.9 to 5.0	0.9 to 4.5	0.8 to 5.0	0.8 to 3.6	1.5 to 5.0

搜尋產品線

Sensor circuit

Example of signal processing circuit for bioelectrical impedance measurement

Small surface mount LDO regulator(1)
Small surface mount LDO regulator(2)
TVS diode
Low noise operational amplifier
Comparator

Small surface mount LDO regulator(1)

器件型號	TCR15AG Series	TCR13AG Series	TCR8BM Series	TCR5BM Series
Toshiba Package Name	WCSP6F	WCSP6F	DFN5B	DFN5B
I_OUT (Max) [mA]	1500	1300	800	500
V_OUT [V]	0.6 to 3.6	0.55 to 3.6	0.8 to 3.6	0.8 to 3.6

搜尋產品線

Small surface mount LDO regulator(2)

器件型號	TCR5RG Series	TCR3RM Series	TCR3U Series	TCR2L Series	TAR5 Series
Toshiba Package Name	WCSP4F	DFN4F	WCSP4F	SOT-553 (ESV)	SOT-25 (SMV)
I_OUT (Max) [mA]	500	300	300	200	200
V_OUT [V]	0.9 to 5.0	0.9 to 4.5	0.8 to 5.0	0.8 to 3.6	1.5 to 5.0

搜尋產品線

TVS diode

器件型號	DF2B7ASL	DF2B5PCT	DF2B7PCT	DF2B7AFU
Toshiba Package Name	SOD-962 (SL2)	SOD-882 (CST2)	SOD-882 (CST2)	SOD-323 (USC)
V_ESD (Max) [kV]	+/-30	+/-30	+/-30	+/-30
I_R (Max) [µA]	0.1	0.1	0.1	0.1
R_dyn (Typ.) [Ω]	0.2	0.1	0.1	0.2
C_T (Typ.) [pF] @ V_R = 0 [V], f = 1 [MHz]	8.5	41	45	8.5

搜尋產品線

Low noise operational amplifier

器件型號	TC75S67TU
Toshiba Package Name	SOT-353F (UFV)
V_CC (Max) [V]	5.5
V_CC, V_EE (Max) [V]	+/-2.75

搜尋產品線

Comparator

器件型號	TC75S70L6X
Toshiba Package Name	MP6C
V_CC (Max) [V]	5.5
V_CC, V_EE (Max) [V]	+/-2.75

搜尋產品線
