TPD1054F

Intelligent power device 40V (Low side switch)

數據表

TPD1054F 數據表/日文[Jul,2024]PDF: 809KB

數據表

TPD1054F 數據表/英文[Jul,2024]PDF: 785KB

Reliability Information

Reliability Data[Oct,2024]PDF: 247KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 85KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 85KB

Application Note

Simplified CFD Model Application Note[Nov,2022]PDF: 993KB

Catalog

Selection Guide Power Devices 2024 Rev2.0[Aug,2024]PDF: 10449KB

數據表

TPD1054F 數據表/日文[Jul,2024]PDF: 809KB

數據表

TPD1054F 數據表/英文[Jul,2024]PDF: 785KB

Application Note

Simplified CFD Model Application Note[Nov,2022]PDF: 993KB

Reliability Information

Reliability Data[Oct,2024]PDF: 247KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 85KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 85KB

Catalog

Selection Guide Power Devices 2024 Rev2.0[Aug,2024]PDF: 10449KB

產品概要

Application Scope Solenoid drivers / Motor drivers / Lamp drivers
Input / Output H/L
Input / Output (Q1) H/L
Number of Circuits 1
Diagnostic Functions Overcurrent / Overtemperature / Open load
Protection Functions Overcurrent / Thermal shutdown / Overvoltage(Active clamp)
AEC-Q100 Qualified(*)
RoHS Compatible Product(s) (#) Available

*: For detail information, please contact to our sales.

包裝資訊

Toshiba Package Name PS-8
Package Image PS-8
Pins 8
Mounting Surface Mount
Width×Length×Height
(mm)		 2.9×2.8×0.8
Package Dimensions 檢視
Land pattern dimensions 檢視

 Please refer to the link destination to check the detailed size.

絕對最大額定值

項目 符號 值 單位
Output Current IO 1.0 A
Power Dissipation PD 0.7 W
Operating Temperature (Max) Topr 125 ℃
Operating Temperature (Min) Topr -40 ℃
Input Voltage (Max) VIN 6 V
Input Voltage (Min) VIN -0.3 V
Power Supply Voltage (Max) VDD 6 V

電器特性

項目 符號 條件 值 單位
ON Resistance (Max) RDS(ON) - 0.8 Ω
Drain-source clamp voltage (Min) V(CL)DSS - 40 V
購買及樣品申請
請聯繫東芝的官方經銷商之一或最近的東芝銷售辦事處
點選以下連結搜索和購買小量樣品

文檔

  • 如果沒看到確認框則對應文件目前無法下載

Oct,2024

Nov,2024

Nov,2024

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS AEC-Q100
AEC-Q101
TPD1054F,LXHF 3000 - Yes Yes

應用

Battery Management System for Automotive
Such as reduction of power consumption and miniaturization are important in battery management system. Toshiba provides information on a wide range of semiconductor products suitable for charging circuit, cell balancing circuit, battery monitoring circuit, etc., along with circuit configuration examples.
詳細資料
Automotive Junction Box
Such as reduction of power consumption and miniaturization are important in junction box. Toshiba provides information on a wide range of semiconductor products suitable for mechanical relay system, semiconductor relay system, etc., along with circuit configuration examples.
詳細資料
Automotive On-board Charger
Such as reduction of power consumption and miniaturization of circuit boards are important in designing on-board charger. Toshiba provides information on a wide range of semiconductor products suitable for DC-DC converter units, power supply units, etc., along with circuit configuration examples.
詳細資料
Automotive Engine Control
Such as reduction of power consumption and miniaturization are important in designing engine control. Toshiba provides information on a wide range of semiconductor products suitable for power management circuit, injector drive circuit, actuator drive circuit, etc., along with circuit configuration examples.
詳細資料
Transmission Management
Such as reduction of power consumption and miniaturization are important in designing transmission management. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, mechanical relay drive units, etc., along with circuit configuration examples.
詳細資料
