SSM3K35FS

Small-signal MOSFET

全部 Data sheet 應用說明 Other

數據表

SSM3K35FS 數據表/日文[Mar,2014]PDF: 265KB

數據表

SSM3K35FS 數據表/英文[Mar,2014]PDF: 206KB

Simulation Model

PSpice Model[Dec,2014]lib: 3KB

Simulation Model

LTspice Model[Feb,2019]mod: 20KB

Reliability Information

Reliability Data[Sep,2024]PDF: 273KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 86KB

Application Note

Surface Mount Small Signal MOSFET Precautions for use[Jan,2022]PDF: 830KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction of Semi-power & small-size low RON MOSFET[Jul,2024]PDF: 441KB

Catalog

Mini catalog Introduction of small-package MOSFET[Jul,2024]PDF: 676KB

數據表

SSM3K35FS 數據表/日文[Mar,2014]PDF: 265KB

數據表

SSM3K35FS 數據表/英文[Mar,2014]PDF: 206KB

Application Note

Surface Mount Small Signal MOSFET Precautions for use[Jan,2022]PDF: 830KB

Simulation Model

PSpice Model[Dec,2014]lib: 3KB

Simulation Model

LTspice Model[Feb,2019]mod: 20KB

Reliability Information

Reliability Data[Sep,2024]PDF: 273KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 86KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction of Semi-power & small-size low RON MOSFET[Jul,2024]PDF: 441KB

Catalog

Mini catalog Introduction of small-package MOSFET[Jul,2024]PDF: 676KB

Application Scope	High-Speed Switching / Analog Switches
Polarity	N-ch
Generation	π-MOSⅥ
Internal Connection	Single
AEC-Q101	Qualified(*)
RoHS Compatible Product(s) (#)	Available

器件型號	兼容性	備註
SSM3K35AFS	Package and characteristics are almost same	-

包裝資訊

Toshiba Package Name	SOT-416 (SSM)
Package Image
JEITA	SC-75
Package Code	SOT-416
Pins	3
Mounting	Surface Mount
Width×Length×Height (mm)	1.6×1.6×0.7
Package Dimensions	檢視
Land pattern dimensions	檢視
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note) Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

絕對最大額定值

項目	符號	值	單位
Drain-Source voltage	V_DSS	20	V
Gate-Source voltage	V_GSS	+/-10	V
Drain current	I_D	180	mA
Power Dissipation	P_D	0.1	W

電器特性

項目	符號	條件	值	單位
Gate threshold voltage (Max)	V_th	-	1.0	V
Gate threshold voltage (Min)	V_th	-	0.4	V
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=1.2V	20	Ω
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=1.5V	8.0	Ω
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=2.5V	4.0	Ω
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=4V	3.0	Ω
Input capacitance (Typ.)	C_iss	-	9.5	pF

文檔

全部選擇
如果沒看到確認框則對應文件目前無法下載

數據表 SSM3K35FS 數據表/日文

PDF: 265KB

Mar,2014

數據表 SSM3K35FS 數據表/英文

PDF: 206KB

Mar,2014

Simulation Model PSpice Model lib

lib: 3KB

Dec,2014

Simulation Model LTspice Model (Note) mod

mod: 20KB

Feb,2019

Reliability Information Reliability Data

PDF: 273KB

Sep,2024

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 86KB

Nov,2024

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 86KB

Nov,2024

Application Note Surface Mount Small Signal MOSFET Precautions for use

PDF: 830KB

Jan,2022

Catalog Selection Guide MOSFETs 2024 Rev2.0

PDF: 10837KB

Jul,2024

Catalog Selection Guide Small Signal 2024 Rev2.0

PDF: 15538KB

Jul,2024

Catalog Mini catalog Introduction of Semi-power & small-size low RON MOSFET

PDF: 441KB

Jul,2024

Catalog Mini catalog Introduction of small-package MOSFET

PDF: 676KB

Jul,2024

(Note)

LTspice ^® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	AEC-Q100 AEC-Q101	Note
SSM3K35FS,LXGF	3000	-	Yes	Yes (Note)	Unintended Use (Note)

應用

Multi Function Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing multi function printer (MFP). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, engine (motor driving) units, scanner units, control units, etc., along with circuit configuration examples.

詳細資料

Inkjet Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing inkjet printer. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, engine (motor driving) units, scanner unit, etc., along with circuit configuration examples.

詳細資料
