XPH8R316MC

Power MOSFET (P-ch single)

數據表

XPH8R316MC 數據表/日文[Apr,2023]PDF: 760KB

數據表

XPH8R316MC 數據表/英文[Apr,2023]PDF: 647KB

Simulation Model

PSpice Model[Jun,2023]ZIP: 11KB

Simulation Model

LTspice Model[Jul,2023]ZIP: 21KB

Simulation Model

SIMetrix Model[Jul,2023]ZIP: 4KB

Thermal Simulation Model

Simplified CFD Model[Aug,2023]ZIP: 8KB

Reliability Information

Reliability Data[Oct,2024]PDF: 273KB

Application Note

Automotive Discrete Semiconductor MBD Introductory Application Note[Mar,2024]PDF: 1522KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

數據表

XPH8R316MC 數據表/日文[Apr,2023]PDF: 760KB

數據表

XPH8R316MC 數據表/英文[Apr,2023]PDF: 647KB

Application Note

Automotive Discrete Semiconductor MBD Introductory Application Note[Mar,2024]PDF: 1522KB

Simulation Model

PSpice Model[Jun,2023]ZIP: 11KB

Simulation Model

LTspice Model[Jul,2023]ZIP: 21KB

Simulation Model

SIMetrix Model[Jul,2023]ZIP: 4KB

Thermal Simulation Model

Simplified CFD Model[Aug,2023]ZIP: 8KB

Reliability Information

Reliability Data[Oct,2024]PDF: 273KB

Catalog

Selection Guide MOSFETs 2024 Rev2.0[Jul,2024]PDF: 10837KB

產品概要

Application Scope DC-DC Converters / Automotive / Motor Drivers / Load Switches
Polarity P-ch
Generation U-MOSⅥ
Internal Connection Single
PPAP Capable(*)
AEC-Q101 Qualified(*)
RoHS Compatible Product(s) (#) Available

*: For detail information, please contact to our sales.

包裝資訊

Toshiba Package Name SOP Advance(WF)
Package Image SOP Advance(WF)
Pins 8
Mounting Surface Mount
Width×Length×Height
(mm)		 5.0×6.0×0.95
Package Dimensions 檢視
Land pattern dimensions 檢視

 Please refer to the link destination to check the detailed size.

絕對最大額定值

項目 符號 值 單位
Drain-Source voltage VDSS -60 V
Gate-Source voltage VGSS +10/-20 V
Drain current ID -90 A
Power Dissipation PD 170 W

電器特性

項目 符號 條件 值 單位
Gate threshold voltage (Max) Vth - -2.1 V
Gate threshold voltage (Min) Vth - -1.0 V
Drain-Source on-resistance (Max) RDS(ON) |VGS|=10V 8.3 mΩ
Drain-Source on-resistance (Max) RDS(ON) |VGS|=4.5V 10.2 mΩ
Input capacitance (Typ.) Ciss - 10500 pF
Total gate charge (Typ.) Qg VGS=-10V 222 nC
Reverse recovery time (Typ.) trr - 113 ns
Reverse recovery charge (Typ.) Qrr - 90 nC
購買及樣品申請
請聯繫東芝的官方經銷商之一或最近的東芝銷售辦事處
點選以下連結搜索和購買小量樣品

文檔

  • 如果沒看到確認框則對應文件目前無法下載

Jun,2023

Jul,2023

Jul,2023

Aug,2023

Oct,2024

(Note1)

LTspice ® is a trademark and simulation software of ADI (Analog Devices, Inc.).

(Note2)

SIMetrix® is simulation software and registered trademarks of SIMetrix Technologies Ltd.

Orderable part number

Orderable part number
(example)		 MOQ(pcs) Reliability
Information		 RoHS AEC-Q100
AEC-Q101
XPH8R316MC,L1Q 5000 Yes -
XPH8R316MC,L1XHQ 5000 - Yes Yes

應用

Automotive Electric Pump (Water/Oil)
Such as ensuring
tolerance to motor lock current and reduction of power consumption are important in electric pump (water/oil). Toshiba provides information on a wide range of semiconductor products suitable for motor drive unit, power supply unit, etc., along with circuit configuration examples.
詳細資料
Advanced Driver-Assistance Systems (ADAS)
Such as reduction of power supply and signal noise and reduction of power consumption are important in designing ADAS. Toshiba provides information on a wide range of semiconductor products suitable for image input units, power supply units, data transmission and audio output units, etc., along with circuit configuration examples.
詳細資料
Automotive Brake Control
Such as reduction of power consumption and miniaturization are important in designing brake control. Toshiba provides information on a wide range of semiconductor products suitable for brake actuator unit, motor driving unit and power supply units, etc., along with circuit configuration examples.
詳細資料
Automotive Electro Active Suspension
Such as reduction of power consumption and miniaturization are important in designing electro active suspension. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, etc., along with circuit configuration examples.
詳細資料
Automotive Engine Control
Such as reduction of power consumption and miniaturization are important in designing engine control. Toshiba provides information on a wide range of semiconductor products suitable for power management circuit, injector drive circuit, actuator drive circuit, etc., along with circuit configuration examples.
詳細資料
IVI (In-vehicle Infotainment)
Such as information sharing and reduction of power consumption are important in designing IVI. Toshiba provides information on a wide range of semiconductor products suitable for display and audio output section, video and voice input section, wireless communications section, etc., along with circuit configuration examples.
詳細資料
Automotive HVAC
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in designing HVAC. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, etc., along with circuit configuration examples.
詳細資料
Automotive LED Headlamp
Such as reduction of power consumption and miniaturization of circuit boards are important in designing LED headlamp. Toshiba provides information on a wide range of semiconductor products suitable for LED matrix control units, power supply units, etc., along with circuit configuration examples.
詳細資料
Automotive Power Slide Door
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in power sliding door. Toshiba provides information on a wide range of semiconductor products suitable for motor drive unit, power supply unit, etc., along with circuit configuration examples.
詳細資料
Automotive Radiator Fan
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in designing radiator fan. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, communication units, etc., along with circuit configuration examples.
詳細資料
Automotive USB Power Charger
Such as reduction of power supply and signal noise and reduction of power consumption are important in designing USB power charger. Toshiba provides information on a wide range of semiconductor products suitable for circuit for cigar socket or accessory circuits, etc., along with circuit configuration examples.
詳細資料
Head-up Display (HUD)
Such as reduction of noise on signal line, reduction of power consumption and miniaturization are important in designing head-up display. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, etc., along with circuit configuration examples.
詳細資料
Electric Power Steering
Such as ensuring tolerance to motor lock current and reduction of power consumption are important in designing electric power steering. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, etc., along with circuit configuration examples.
詳細資料
Transmission Management
Such as reduction of power consumption and miniaturization are important in designing transmission management. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, power supply units, mechanical relay drive units, etc., along with circuit configuration examples.
詳細資料
