TCR1HF50B

Low Dropout (LDO) Linear Voltage Regulator

  • 相關參考設計(3)

數據表

TCR1HF50B 數據表/日文[Nov,2024]PDF: 2806KB

數據表

TCR1HF50B 數據表/英文[Nov,2024]PDF: 2554KB

Reliability Information

Reliability Data[Oct,2024]PDF: 245KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 86KB

Application Note

LDO Regulator Application to Power Supplies for High-Frequency Circuits[Apr,2022]PDF: 3288KB

Application Note

Basics of Low-Dropout (LDO) Regulator ICs[Mar,2021]PDF: 1296KB

Application Note

LDO Regulators Glossary[Mar,2021]PDF: 341KB

Application Note

Dual power supply LDO Regulators for Low Drop Out and Low Loss at low Voltage[Mar,2021]PDF: 790KB

Application Note

Concept of self-heating of LDOs and selection guide[Mar,2021]PDF: 739KB

Application Note

Improving the Load Transient Response of LDOs[Mar,2021]PDF: 1162KB

Application Note

Simple Guide to Improving Ripple Rejection Ratio of LDO Regulators[Mar,2021]PDF: 1249KB

Application Note

Mechanism of LDO Oscillation and Reducing the Susceptibility to Oscillation[Mar,2021]PDF: 1375KB

Application Note

LDO Regulator Application to Power Supply Circuits for Digital Cores of CMOS Image Sensors[Oct,2020]PDF: 2482KB

Application Note

LDO Regulator Application to Power Supply Circuits for MCUs[Oct,2020]PDF: 2575KB

Catalog

Mini catalog Introduction of Toshiba compact LDO regulators[Aug,2024]PDF: 612KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Toshiba's circuit protection solutions and switch solutions[Aug,2023]PDF: 523KB

數據表

TCR1HF50B 數據表/日文[Nov,2024]PDF: 2806KB

數據表

TCR1HF50B 數據表/英文[Nov,2024]PDF: 2554KB

Application Note

LDO Regulator Application to Power Supplies for High-Frequency Circuits[Apr,2022]PDF: 3288KB

Application Note

Basics of Low-Dropout (LDO) Regulator ICs[Mar,2021]PDF: 1296KB

Application Note

LDO Regulators Glossary[Mar,2021]PDF: 341KB

Application Note

Dual power supply LDO Regulators for Low Drop Out and Low Loss at low Voltage[Mar,2021]PDF: 790KB

Application Note

Concept of self-heating of LDOs and selection guide[Mar,2021]PDF: 739KB

Application Note

Improving the Load Transient Response of LDOs[Mar,2021]PDF: 1162KB

Application Note

Simple Guide to Improving Ripple Rejection Ratio of LDO Regulators[Mar,2021]PDF: 1249KB

Application Note

Mechanism of LDO Oscillation and Reducing the Susceptibility to Oscillation[Mar,2021]PDF: 1375KB

Application Note

LDO Regulator Application to Power Supply Circuits for Digital Cores of CMOS Image Sensors[Oct,2020]PDF: 2482KB

Application Note

LDO Regulator Application to Power Supply Circuits for MCUs[Oct,2020]PDF: 2575KB

Reliability Information

Reliability Data[Oct,2024]PDF: 245KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Dec,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Dec,2024]PDF: 86KB

Catalog

Mini catalog Introduction of Toshiba compact LDO regulators[Aug,2024]PDF: 612KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Toshiba's circuit protection solutions and switch solutions[Aug,2023]PDF: 523KB

產品概要

Application Consumer equipment / Industrial power supply / Mobile equipment / Camera/Sensor power supply / General purpose power supply
Feature Wide range input voltage / Low dropout voltage / Low quiescent current / Fast load transient response
Output Type Fixed Output
Overcurrent protection Y
Thermal shutdown Y
Inrush current reduction Y
RoHS Compatible Product(s) (#) Available

包裝資訊

Toshiba Package Name SOT-25 (SMV)
Package Image SMV
JEITA SC-74A
Package Code SOT-25
Pins 5
Mounting Surface Mount
Width×Length×Height
(mm)		 2.9×2.8×1.1
Package Dimensions 檢視
Land pattern dimensions 檢視

 Please refer to the link destination to check the detailed size.

絕對最大額定值

項目 符號 值 單位
Input Voltage VIN 40 V
Power Dissipation (mounted on glass-epoxy board(25.4mm×25.4mm)) PD 580 mW

電器特性

項目 符號 條件 值 單位
Operating Output Current (Max) IOUT - 150 mA
Operating Input Voltage * VIN - 4 to 36 V
Output Voltage (Typ.) VOUT - 5.0 V
Output Voltage Lineup VOUT - 1.8 to 5.0 V
Quiescent Current (Typ.) * IB(ON) IOUT=0mA 1.0 μA
Stand-by Current (Typ.) * IB(OFF) - 0.27 μA
Dropout Voltage (Typ.) * VDO IOUT=0.15A 415 mV
Ripple Rejection Ratio (Typ.) * R.R. f=1kHz 60 dB
Output Noise Voltage (Typ.) * VNO - 100 μVrms
Operating Temperature Topr - -40 to 125 ℃
Output Capacitance COUT - ≥0.47 μF

 *: Representative value, Please refer to the datasheet for details.
