2SA1586

Transistor for low frequency small-signal amplification

全部 Data sheet 應用說明 Other

數據表

2SA1586 數據表/日文[Jul,2021]PDF: 301KB

數據表

2SA1586 數據表/英文[Jul,2021]PDF: 303KB

Simulation Model

PSpice Model[Dec,2016]ZIP: 2KB

Simulation Model

LTspice Model[Mar,2019]ZIP: 6KB

Reliability Information

Reliability Data[Sep,2024]PDF: 276KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 86KB

Application Note

Surface Mount Small Signal Transistor (BJT) Precautions for use[Jan,2022]PDF: 732KB

Application Note

The thermal stability and thermal design:Bipolar Transistor Application Notes[Mar,2021]PDF: 525KB

Application Note

The maximum ratings:Bipolar Transistor Application Notes[Mar,2021]PDF: 615KB

Application Note

The electrical characteristics and equivalent circuit:Bipolar Transistor Application Notes[Jan,2021]PDF: 513KB

Application Note

The terms used in data sheets:Bipolar Transistor Application Notes[Jan,2021]PDF: 546KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction to Toshiba small package Bipolar Transistors[Jul,2024]PDF: 438KB

數據表

2SA1586 數據表/日文[Jul,2021]PDF: 301KB

數據表

2SA1586 數據表/英文[Jul,2021]PDF: 303KB

Application Note

Surface Mount Small Signal Transistor (BJT) Precautions for use[Jan,2022]PDF: 732KB

Application Note

The thermal stability and thermal design:Bipolar Transistor Application Notes[Mar,2021]PDF: 525KB

Application Note

The maximum ratings:Bipolar Transistor Application Notes[Mar,2021]PDF: 615KB

Application Note

The electrical characteristics and equivalent circuit:Bipolar Transistor Application Notes[Jan,2021]PDF: 513KB

Application Note

The terms used in data sheets:Bipolar Transistor Application Notes[Jan,2021]PDF: 546KB

Simulation Model

PSpice Model[Dec,2016]ZIP: 2KB

Simulation Model

LTspice Model[Mar,2019]ZIP: 6KB

Reliability Information

Reliability Data[Sep,2024]PDF: 276KB

Environment Information

Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances[Nov,2024]PDF: 86KB

Environment Information

Certificate on Content of SVHC of REACH[Nov,2024]PDF: 86KB

Catalog

Selection Guide Small Signal 2024 Rev2.0[Jul,2024]PDF: 15538KB

Catalog

Mini catalog Introduction to Toshiba small package Bipolar Transistors[Jul,2024]PDF: 438KB

產品概要

Application Scope	General-purpose
Polarity	PNP
Complementary Product	2SC4116
Comments	Rank is specified by hFE range.
PPAP	Capable(*)
AEC-Q101	Qualified(*)
RoHS Compatible Product(s) (#)	Available

*: For detail information, please contact to our sales.

包裝資訊

Toshiba Package Name	SOT-323 (USM)
Package Image
JEITA	SC-70
Package Code	SOT-323
Pins	3
Mounting	Surface Mount
Width×Length×Height (mm)	2.0×2.1×0.9
Package Dimensions	檢視
Land pattern dimensions	檢視
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note) Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

絕對最大額定值

項目	符號	值	單位
Collector Current	I_C	-0.15	A
Collector-emitter voltage	V_CEO	-50	V

電器特性

項目	符號	條件	值	單位
DC Current Gain hFE (Max)	h_FE	I_C=-0.002A V_CE=-6V	400	-
DC Current Gain hFE (Min)	h_FE	I_C=-0.002A V_CE=-6V	70	-
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	I_B=-10mA I_C=-0.1A	-0.3	V
Transition frequency (Min)	f_T	I_C=-0.001A V_CE=-10V	80	MHz

購買及樣品申請

請聯繫東芝的官方經銷商之一或最近的東芝銷售辦事處

全球銷售辦事處

點選以下連結搜索和購買小量樣品

線上庫存查詢跟購買

Orderable part number

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	AEC-Q100 AEC-Q101	Note
2SA1586-GR,LF	3000		Yes	-	General Use
2SA1586-GR,LXGF	3000	-	Yes	Yes (Note)	Unintended Use (Note)
2SA1586-GR,LXHF	3000	-	Yes	Yes	Automotive Use
2SA1586-Y,LF	3000		Yes	-	General Use
2SA1586-Y,LXGF	3000	-	Yes	Yes (Note)	Unintended Use (Note)
2SA1586-Y,LXHF	3000	-	Yes	Yes	Automotive Use

(Note)：For more information, please contact our sales or use the inquiry form on our website.
